First time read. Now sub’d.
IMO, your engine choice and placement scream for a 60series/Scout power steering conversion, as the conventional Saginaw setup will require a two piece center shaft and support bearing, which is substandard.
Here’s a pic of an egregious one that came into my shop a year and a half ago
IMO, your engine choice and placement scream for a 60series/Scout power steering conversion, as the conventional Saginaw setup will require a two piece center shaft and support bearing, which is substandard.
Here’s a pic of an egregious one that came into my shop a year and a half ago
- Thread starter
- #45
- Joined
- Apr 14, 2004
- Threads
- 1,391
- Messages
- 35,255
- Location
- 818-953-9230
- Website
- www.marksoffroad.net
Don’t cut anything until you have a FULL game plan. Like welding in a new steering box mount before knowing where your engine was gonna be wasn’t such a good idea.
So, theoretically, how would steering shaft alignment look if it was going from the firewall over the TOP of the framerail to a Scout/60 box?
So, theoretically, how would steering shaft alignment look if it was going from the firewall over the TOP of the framerail to a Scout/60 box?
- Thread starter
- #47
I think I can make the saginaw setup work fine (especially if I relocate the PS pump to make room). But i cant be sure until i mockup the column, but i need to remove it from the parts truck...I'm simply asking what's the best way to get it apart from the factory box and out of the parts truck.
- Thread starter
- #48
Update time once again...So last night while I was waiting to see if anyone responds to the post before this asking how you take a pre '72 steering column off the box I decided to attack the fuel tank!
So, first things first, I opened up the hole a bit more just to be sure i've cut back to the most solid material available.
Next I cut out a piece of angle steel to fit the hole as tight as possible.
And burned it in for good.
I also did some work on the pin hole area that was leaking when I water tested it. After I finished I rigged up the hoses with a plug/press. gauge/ needle valve setup and pressurized the tank and left it overnight...no leaks! Today I filled it with water again just for good measure and confirmed...no leakage. It's got a couple other small pitted areas that Ill fix after I sandblast it and can see the whole deal.
Anyway, this afternoon I decided to cut the '70 steering column off the factory box because I really didn't want to wait any longer to mock-up the steering shaft. I'm glad I did, I don't see how you can take the old style box/column apart otherwise. Anyway, I mocked up the '70 column in the truck and used the Spud shaft/U-joint and steering shaft that came with the '72.
So that'll work with no issues! I'll likely buy a 3/4 DD collapsible assembly to replace most of the shaft in the pictures (so I have the collapsible area for frame flex) then buy a 3/4 DD u-joint and mill flats on the factory 3/4 shaft/column.
So now that I know this will all work I decided to finish one of the bottom steering box mounts...
So I notched out the frame
Cut a section of pipe and bolted it in through the notch, tighted it up, tack welded it, removed the bolt, welded the pipe in completely. (not pictured)
And ground it all off flat.
I've still got to finish the bottom front mount...that's gonna be the worst one.
Next thing is gonna be removing the tub, blasting the whole chassis, POR15 on the chassis, clean and paint the engine/trans/tcase and start putting it back together.
So, first things first, I opened up the hole a bit more just to be sure i've cut back to the most solid material available.
Next I cut out a piece of angle steel to fit the hole as tight as possible.
And burned it in for good.
I also did some work on the pin hole area that was leaking when I water tested it. After I finished I rigged up the hoses with a plug/press. gauge/ needle valve setup and pressurized the tank and left it overnight...no leaks! Today I filled it with water again just for good measure and confirmed...no leakage. It's got a couple other small pitted areas that Ill fix after I sandblast it and can see the whole deal.
Anyway, this afternoon I decided to cut the '70 steering column off the factory box because I really didn't want to wait any longer to mock-up the steering shaft. I'm glad I did, I don't see how you can take the old style box/column apart otherwise. Anyway, I mocked up the '70 column in the truck and used the Spud shaft/U-joint and steering shaft that came with the '72.
So that'll work with no issues! I'll likely buy a 3/4 DD collapsible assembly to replace most of the shaft in the pictures (so I have the collapsible area for frame flex) then buy a 3/4 DD u-joint and mill flats on the factory 3/4 shaft/column.
So now that I know this will all work I decided to finish one of the bottom steering box mounts...
So I notched out the frame
Cut a section of pipe and bolted it in through the notch, tighted it up, tack welded it, removed the bolt, welded the pipe in completely. (not pictured)
And ground it all off flat.
I've still got to finish the bottom front mount...that's gonna be the worst one.
Next thing is gonna be removing the tub, blasting the whole chassis, POR15 on the chassis, clean and paint the engine/trans/tcase and start putting it back together.
