Intake/ Exhaust Gasket (1 Viewer)

Trollhole

THC
Supporting Vendor
Moderator
Joined
Mar 6, 2005
Messages
21,018
Location
Mauldin, SC
Website
forum.ih8mud.com
Got to get a new one

2f 1 piece headers. The old one leaks bad out the exhaust and I'm dieseling. Whats a good replacement.

And don't tell me to search.:flipoff2: Unless this topic was covered in 03 cause the search function has a few issues.

And no specter stuff. I'm officially boycotting them for life.

Joined
Jul 2, 2002
Messages
1,373
Location
New Hampshire
I have had good luck with the ones off the shelf from napa. Of course I bought a new downey header like 3 years ago and haven't changed out their gasket yet either. Specters kevlar gasket sucks.

Joined
Jan 3, 2003
Messages
7,184
Location
McCall, ID
Yup, OEM or felpro. 1 Piece headers are tough. Consider double gasketing.

Joined
Oct 8, 2003
Messages
462
Location
Near Junk
All the experts here seem to suggest doubling up gaskets if you have headers - and go OEM. 2nd the CDan plug - but sh&t from him - he's the best.

AndrewT

Joined
Oct 31, 2003
Messages
5,010
Location
Meridian,TEXAS
Have it resurfaced... & use 2 felpro & high temp silicone

Joined
Jan 22, 2003
Messages
8,118
Location
Kansastitty
All good advice, and I would only add: Retorque X as many times as it takes for it not to change, then still check it. This is not a 2f-specific problem although more of a problem with a 1 piece 6 cyl header than a side of a V8. The steel expands and contracts much differently than the cast iron. If you do retorque, you will be surprised how much it will change. Once the gasket is breached and the hot exhaust gasses have their way with it, you are into a redo.
Use OEM and/or FelPro(actually I used one of each and doubled mine) and check the torque.
J-M-O..FWIW...........my headers have never leaked and I learned it right here on MUD!


Ed


FJ40Jim

The Cruiser Whisperer
SILVER Star
Joined
Sep 26, 2003
Messages
11,184
Location
Lancaster, Ohio, USA
Website
www.tlcperformance.com
Trollhole said:
Got to get a new one
2f 1 piece headers. The old one leaks bad out the exhaust and I'm dieseling. Whats a good replacement.
Ya know, this is prolly in the archive if you'd searched:rolleyes:

The FelPro graflex manifold gasket is the best. If you get any other brand, it will be the same as the junk foil OEM gasket.

And don't tell me to search.:flipoff2:
Oh sorry:D

And no specter stuff. I'm officially boycotting them for life.
Cool, me too!
Let's start a club. The he-man overpriced, lying SOR haters club.:ban:


Trollhole

THC
Supporting Vendor
Moderator
Joined
Mar 6, 2005
Messages
21,018
Location
Mauldin, SC
Website
forum.ih8mud.com
toddslater said:
Well...yes it was covered in 03....

https://forum.ih8mud.com/showthread.php?t=819&highlight=felpro

probably back in 02 as well.....

Sorry couldn't resist....well at least the search function seems to be back and working today :cheers:


Now how in the hell was I supposed to know to search for felpro? And the title of that post is "a simple question" Not very descriptive.

I saved this just incase someone thought someone would throw it back at me.

So:flipoff2:



Anyway thanks for the link. And everyone elses response.

:beer: :beer: :beer:

Last edited:

Trollhole

THC
Supporting Vendor
Moderator
Joined
Mar 6, 2005
Messages
21,018
Location
Mauldin, SC
Website
forum.ih8mud.com
Well I'm pissed. I just put in two stacked toyota gaskets and I still have the leaks in the same place. I even used copper sealant and it still leaks.:mad:

I guess new headers are in my future.

Joined
Oct 31, 2002
Messages
1,501
Location
Kennett Square
Mother Mary and Joseph :eek: Double G's and goo and it's still leaking. Pics or description of just exactly where the breach is occurring. But I think if the double G and goo failed that little bastage gotta be warped. When you get it off, put a straight edge across it....should confirm/coincide with the leak...get it machined flat and reinstall with double G and goo.

Joined
Jan 19, 2003
Messages
688
Will the FelPro gasket, which is listed by FelPro as being only for the 2F engine also fit an F engine?


Poser

Oh...Durka Durka Durka.
Supporting Vendor
Joined
Oct 1, 2003
Messages
20,465
Location
MN
rgentry said:
Will the FelPro gasket, which is listed by FelPro as being only for the 2F engine also fit an F engine?




Fit? Yes, it will "fit".


Will it work properly, being that it will not be centered on the intake and exhaust ports and allowed to move, as the fastners used for the F engine are 10mm diameter studs and the 2F are a 12mm diameter, I do not know....I have not ever tried it.


SOR only sells one 'kevlar' gasket for both engines....so it may work....



Good luck!


-Steve


Poser

Oh...Durka Durka Durka.
Supporting Vendor
Joined
Oct 1, 2003
Messages
20,465
Location
MN
Trollhole said:
Well I'm pissed. I even used copper sealant and it still leaks..


Copper sealant.....spray on, or silicone stuff?



Did you find a place to mill the flange?



Was good talking with you this morning bud...



:beer:


Trollhole

THC
Supporting Vendor
Moderator
Joined
Mar 6, 2005
Messages
21,018
Location
Mauldin, SC
Website
forum.ih8mud.com
Poser said:
Copper sealant.....spray on, or silicone stuff?



Did you find a place to mill the flange?



Was good talking with you this morning bud...



:beer:


silicon.


well I found the problem. when i broke 2 motor mounts wheeling. the engine was flailing around inside the engine compartment. it must have torqued the header. i should have known to check to make sure it was flat when i had it off. stupid me. i cut a couple of small wedges of metal a pounded them in between the 2 gaskets. will work until i can get one from marks off road.

i also managed to cut my finger and burn 3 others in the process. so i'm typing with one hand [so no caps]

thanks everyone for input.

steve thanks for the ideas this morning.


Poser

Oh...Durka Durka Durka.
Supporting Vendor
Joined
Oct 1, 2003
Messages
20,465
Location
MN
Sorry to hear about your hand pal....


Post up how the new one works!


:beer:


cruiserjunktion

Cruiserjunktion@gmail.com
GOLD Star
Joined
May 19, 2005
Messages
6,516
Location
North Florida
sor's kevlar gasket didn't work for me...

although the gasket is supplied with the 2 piece header, it wasn't port matched.

trimming is needed for a proper fit.....

I threw mine in the trash and got a nice metal one from tpi4x4.com

http://www.tpi4x4.com/05-lcHeaders.html

It lines up PERFECTLY, and is THICK too...... .$23.80


waiting on carb rebuild to try it out
