Cooling a V8 with AC, my solution.....new radiator
I decided to do a little write up on my radiator upgrade that I am currently working on. After installing AC last summer I had had some issues with water temps while sitting in traffic on hot days. So I decided to change out the radiator and try to solve the issue once and for all. With the AC condenser up front it left very little room for a transmission cooler, so I decided I wanted the new radiator to have an internal transmission cooler. I also wanted at least 1.25” internal rows to allow for better cooling. I measured the opening and decided that a 26” x 19” radiator would work well. After doing a lot of research I ended up ordering a Griffin GRI-1-85222-T radiator.
[URL="http://i44.tinypic.com/103g3df.jpg%5b/IMG"]http://i44.tinypic.com/103g3df.jpg[/IMG[/URL]]
Obviously this radiator would not work in the factory u support so I had to construct a new mounting system. I picked up 2 six foot pieces of 2” angle iron that is 1/8” thick to make a “u” that the radiator would fit in and a 3” wide ¼” flat bar for the top plate.
[IMG][URL="http://i39.tinypic.com/242wym8.jpg%5b/IMG"]http://i39.tinypic.com/242wym8.jpg[/IMG[/URL]]
[IMG][URL="http://i43.tinypic.com/sg48l1.jpg%5b/IMG"]http://i43.tinypic.com/sg48l1.jpg[/IMG[/URL]]
Once the angle iron was cut and tacked together I had to figure out how big the feet needed to be to position the radiator at the proper height.
[IMG][URL="http://i40.tinypic.com/2cdygp4.jpg%5b/IMG"]http://i40.tinypic.com/2cdygp4.jpg[/IMG[/URL]]
While I had the front off and access I wanted to add enough room for a third pulley on the crank to allow for power steering in the future. In order to accomplish this I needed a ½” spacer between the water pump and fan. I called all the local sources and no one had one. My dad said, ‘I think I had one that I tried on my 57 Chevy years ago, I bet it’s around here somewhere.” 30 minutes later, he returned with this.
[IMG][URL="http://i43.tinypic.com/2e3mipi.jpg%5b/IMG"]http://i43.tinypic.com/2e3mipi.jpg[/IMG[/URL]]
After 42 years he still had it and was able to locate it. I was shocked! Thanks dad! Popped it and now I have enough clearance to run a triple crank pulley. I wanted to be able to isolate the radiator in the support bracket to cut down on vibrations. I used 1/8” and ¼” rubber to do this so there is no metal to metal contact. This is a picture of the engine side of the bracket with the top plate installed.
[IMG][URL="http://i44.tinypic.com/219c2ad.jpg%5b/IMG"]http://i44.tinypic.com/219c2ad.jpg[/IMG[/URL]]
I used some 2.5” square tubing and ¼” plate to build feet for the radiator to sit on. I am using ½” thick shock absorber rubber washers to isolate the bracket from the frame.
[IMG][URL="http://i39.tinypic.com/rsz8zq.jpg%5b/IMG"]http://i39.tinypic.com/rsz8zq.jpg[/IMG[/URL]]
I used 3/8” steel rod to replicate the factory supports to add strength on both sides.
[IMG][URL="http://i42.tinypic.com/4gp5pw.jpg%5b/IMG"]http://i42.tinypic.com/4gp5pw.jpg[/IMG[/URL]]
[IMG][URL="http://i39.tinypic.com/i1cfut.jpg%5b/IMG"]http://i39.tinypic.com/i1cfut.jpg[/IMG[/URL]]
This is a front shot that shows the front bib in place. You can see the tabs I tacked in place to mount the condenser to. It leaves a 3/8” between the condenser and radiator which I think will work great. The tabs were made from 1/8” material and tapped to accommodate the fasteners for the condenser.
[IMG][URL="http://i42.tinypic.com/ne81dz.jpg%5b/IMG"]http://i42.tinypic.com/ne81dz.jpg[/IMG[/URL]]
I ran out of time and had to head back to school today so I will have to finish it next weekend. I still have to add a bracket for the dryer and address mounting for the horns and the fj60 overflow tank. Then I can finish all the weld s and concentrate on the shroud. Then a little paint and I can try it out. I will add more pictures this weekend as I make more progress. Thanks
I decided to do a little write up on my radiator upgrade that I am currently working on. After installing AC last summer I had had some issues with water temps while sitting in traffic on hot days. So I decided to change out the radiator and try to solve the issue once and for all. With the AC condenser up front it left very little room for a transmission cooler, so I decided I wanted the new radiator to have an internal transmission cooler. I also wanted at least 1.25” internal rows to allow for better cooling. I measured the opening and decided that a 26” x 19” radiator would work well. After doing a lot of research I ended up ordering a Griffin GRI-1-85222-T radiator.
[URL="http://i44.tinypic.com/103g3df.jpg%5b/IMG"]http://i44.tinypic.com/103g3df.jpg[/IMG[/URL]]
Obviously this radiator would not work in the factory u support so I had to construct a new mounting system. I picked up 2 six foot pieces of 2” angle iron that is 1/8” thick to make a “u” that the radiator would fit in and a 3” wide ¼” flat bar for the top plate.
[IMG][URL="http://i39.tinypic.com/242wym8.jpg%5b/IMG"]http://i39.tinypic.com/242wym8.jpg[/IMG[/URL]]
[IMG][URL="http://i43.tinypic.com/sg48l1.jpg%5b/IMG"]http://i43.tinypic.com/sg48l1.jpg[/IMG[/URL]]
Once the angle iron was cut and tacked together I had to figure out how big the feet needed to be to position the radiator at the proper height.
[IMG][URL="http://i40.tinypic.com/2cdygp4.jpg%5b/IMG"]http://i40.tinypic.com/2cdygp4.jpg[/IMG[/URL]]
While I had the front off and access I wanted to add enough room for a third pulley on the crank to allow for power steering in the future. In order to accomplish this I needed a ½” spacer between the water pump and fan. I called all the local sources and no one had one. My dad said, ‘I think I had one that I tried on my 57 Chevy years ago, I bet it’s around here somewhere.” 30 minutes later, he returned with this.
[IMG][URL="http://i43.tinypic.com/2e3mipi.jpg%5b/IMG"]http://i43.tinypic.com/2e3mipi.jpg[/IMG[/URL]]
After 42 years he still had it and was able to locate it. I was shocked! Thanks dad! Popped it and now I have enough clearance to run a triple crank pulley. I wanted to be able to isolate the radiator in the support bracket to cut down on vibrations. I used 1/8” and ¼” rubber to do this so there is no metal to metal contact. This is a picture of the engine side of the bracket with the top plate installed.
[IMG][URL="http://i44.tinypic.com/219c2ad.jpg%5b/IMG"]http://i44.tinypic.com/219c2ad.jpg[/IMG[/URL]]
I used some 2.5” square tubing and ¼” plate to build feet for the radiator to sit on. I am using ½” thick shock absorber rubber washers to isolate the bracket from the frame.
[IMG][URL="http://i39.tinypic.com/rsz8zq.jpg%5b/IMG"]http://i39.tinypic.com/rsz8zq.jpg[/IMG[/URL]]
I used 3/8” steel rod to replicate the factory supports to add strength on both sides.
[IMG][URL="http://i42.tinypic.com/4gp5pw.jpg%5b/IMG"]http://i42.tinypic.com/4gp5pw.jpg[/IMG[/URL]]
[IMG][URL="http://i39.tinypic.com/i1cfut.jpg%5b/IMG"]http://i39.tinypic.com/i1cfut.jpg[/IMG[/URL]]
This is a front shot that shows the front bib in place. You can see the tabs I tacked in place to mount the condenser to. It leaves a 3/8” between the condenser and radiator which I think will work great. The tabs were made from 1/8” material and tapped to accommodate the fasteners for the condenser.
[IMG][URL="http://i42.tinypic.com/ne81dz.jpg%5b/IMG"]http://i42.tinypic.com/ne81dz.jpg[/IMG[/URL]]
I ran out of time and had to head back to school today so I will have to finish it next weekend. I still have to add a bracket for the dryer and address mounting for the horns and the fj60 overflow tank. Then I can finish all the weld s and concentrate on the shroud. Then a little paint and I can try it out. I will add more pictures this weekend as I make more progress. Thanks
