Yes, it is readily apparent to me that Scott is not well versed in control engineering and the dynamics a feedback system like the LandCruiser's closed loop EFI system. Nor is he particularly well versed in the design of analog and digital sensor systems..... to feed the system's instantaneous input vectors in its state space representation....
Hunh?!
That was very impressive wording that doesn't address how the ECU works in the 80, or really any other EFI system. MAF input is strictly a function of voltage drop from airflow through a given size tube. The
software dictates what that voltage function is, how accurate it is, it's upper and lower limits, and it's 'resolution'. Why? Because you haven't done anything to recalibrate the A/D converter (FYI - technically referred to MAF transfer function).
What Toyota Engineers do (along with most any other oem or aftermarket tuner), is they take various 'Load Values' and create a Map for fuel and ignition tables (Speed Density uses Manifold Absolute Pressure Sensor for Load, Mass Air uses MAF sensor for Load). If you look at the Toyota documentation regarding ignition tables I referenced, if the MAF reading is off, so is the Load Value. The Load Value is off, so is the fuel and ignition table for any given RPM. Load Value for ignition is strictly a MAF vs RPM table. 80 ignition tables from MAF sensor voltage are *only*
corrected by engine temp and knock sensor intervention, that's it. How do I know that? Because Mr. T documents that.
There is no knickity-snickity black box vectoring stuff going into all this. Every stock oem software program I've seen uses this formula for 'ideal' airflow (WOT)
Engine CID x .5 x Volumetric Efficiency x rpm/1728 = CFM
Convert to Mass of Air = CFM x Density Ratio (air temp and pressure correction) = gm/s (WOT ideal)
Load is then corrected via the MAF value. For instance, if at 4000rpm the 80 is 40gm/s using the above tabled Ideal Value (Theoretical Airmass), and you have a MAF airflow value measured value of 20gm/s (Actual Airmass), a Load Value of 50% is used in the fuel and spark Maps. Simply put in a Mass Airflow Ecu:
Load Value = Current Airmass/Theoretical Airmass
The Toyota Engineers spend a lot of time on the dyno and in testing to determine what the highest possible incoming air is for the 80 engine and determine a very accurate VE and Theoretical Airmass using the equation above. They then assign this the software max MAF value of 5v. Then the voltage slope of the MAF has the widest 'resolution' to the actual air demand of the engine.
When Toyota designed the stock MAF, the obstructions inserted into the tube are used to manipulate airflow to give more accurate airflow at low values. If you look in the bore of the MAF B (Stock) vs the MAF A (modded), the airflow is of higher velocity at lower values, to give a more accurate voltage value at low actual airflow. That 'resolution' is *expected* in the software transfer function of MAF voltages. Read: The inserted airflow obstructions in a given tube change the MAF voltage slope, which is then programmed in the software.
This means any deviation from the *expected* airflow voltage value as measured by the MAF, is just summarily:
incorrect. Many opin here it's better, more accurate, has better S/N, etc... All incorrect assumptions, because a MAF meter is not calibrated in the tube, it's calibrated in the MAF Transfer function A/D tables of the software (see Christo's comments page 3). And it defines Load.
When doing base Maps for standalone, I use the above formulas to get a car started and running. Then use dyno and driving time to tweek the MAF transfer function values to give the most accurate MAF values possible. FYI in oem systems, this MAF value is in the 1% accuracy range, and most tuners like to stay as close to this as possible. Why? Because the more accurate your actual measure of incoming air, the less work you have to do elsewhere.
YOMV
Scott J
94 FZJ80 Supercharged
