Home Made Tools

[Tysano]

Craftsman makes a tool that is perfect for removing hoses... $2.47 each, not worth making your own.
That is a window/windshield, installation tool
Sears.com



[Tysano]

thats actually for removing cotter keys , but works for hoses .

nope it is a window/ windshield installation, tool



[98 SNAKE EATER]

Mocked up another inflator

With the valve closed, left gauge reads tire pressure and right gauge reads source pressure

Open it up and they equalize

And the larger screw on chuck is easier on the fingertips than the dually extensions on my old setup

Leak free and painless compared to inflators with clip on leads and momentary valves



[73fj]

My home made wheel bearing puller for my 40, the key is fed through the bearing and when pulled back lays flat against the inside of the bearing, slide the long tube back and you have a slide hammer type action, works like a charm.



[chap79]

Press brake made from a HF shop press.

Have bent up to 3/8" plate with it.



[tibby]

Can i share my diagnosis tool in here??? foxwell nt510 is very eazy to use and powrful ,best tool at home



[Blue77FJ40]

Can i share my diagnosis tool in here??? foxwell nt510 is very eazy to use and powrful ,best tool at home

Care to elaborate? Pics?



[pb4ugo]

My home made wheel bearing puller for my 40, the key is fed through the bearing and when pulled back lays flat against the inside of the bearing, slide the long tube back and you have a slide hammer type action, works like a charm.

View attachment 1286266

View attachment 1286267

View attachment 1286268

Nice tool, great idea, but there's an easier way. Remove the spindle nuts, remove the outer bearing, leave the rotor on, and reinstall 1 spindle nut, then grab the rotor at 3 and 9 o'clock and slide the rotor off with some force. You'll end up with the rotor in you're hands and the inner bearing and seal will be on the spindle.



[LAMBCRUSHER]

Press brake made from a HF shop press.

Have bent up to 3/8" plate with it.

I cant see the pics, do you have a link?



[chap79]

I cant see the pics, do you have a link?

Fixed it



[BMThiker]

Before my dad passed away 2 years ago, he was having to change IV bags at home. He had trouble with the push to connect fittings so I made him a tool from a pair of channel locks that would let him squeeze the plastic fittings together without breaking them. It worked like a charm.



[KLF]

Nice tool, great idea, but there's an easier way. Remove the spindle nuts, remove the outer bearing, leave the rotor on, and reinstall 1 spindle nut, then grab the rotor at 3 and 9 o'clock and slide the rotor off with some force. You'll end up with the rotor in you're hands and the inner bearing and seal will be on the spindle.

Umm... Pretty sure he's talking about the rear axle, not the front.



[98 SNAKE EATER]

Mocked up a couple more inflators

This one has larger ports and tubing for more flow:

And this one has dual outlets (lock the main and opposing valves to check pressure)



[Tin basher]

One piece transfer case puller from scrap.

View attachment 1257396

Thanks jb

. This makes mine the welfare version I drilled a hole in a stock t case cover welded a nut to it and a piece of all thread with a nut welded to it works great



[LAMBCRUSHER]

. This makes mine the welfare version I drilled a hole in a stock t case cover welded a nut to it and a piece of all thread with a nut welded to it works great



[SMG]

Mounted this piece of aluminum plate to my Harbor Frieght Band saw. Now I can use it as an upright for cutting smaller pieces and shapes.



[e9999]

SMG, they (the green ones) used to come with a table like that. It mounted directly on the blade guide. And I've seen one guide broken because of it.



[LAMBCRUSHER]

on a HF tool? NO WAY!



[SMG]

I think this is a step above HF saw. It has bearings for the guides as the HF does not. The castings are the same.
It's been working great!



[BMThiker]

I saw one of these recently and it was pretty cool. SWAG V3.0 Portaband Table
