2015 LC200 Phoenix Automative G6 Octa Core install (1 Viewer)

[re500]

There is a lot of information about the PX6 head unit, but my factory head unit initially started flickering and eventually stopped booting altogether. I tried to fix it at a local repair shop, but the power module alone would cost $1500 to replace. Instead of spending that much on repairs, I decided to upgrade to a “Tesla”-style head unit. Will update the thread with more information as I progress with the install.

Why Upgrade?
My initial research led me to the PX6 head unit with Sergey Custom ROM, which is an amazing ROM, but the hardware itself is outdated. Since I wanted a more modern solution, I went ahead with the Phoenix Automotive G6 Octa-Core.

Product Link:
Phoenix Automotive G6 Octa-Core 16” Vertical Screen
This unit is essentially the same as the one available at:
Zhifang GPS

The model number is 1806GE

For reference, here is the Google Drive link to confirm compatibility with the North American Toyota Land Cruiser LC200:
Drive File

Technical Specifications

Processor & OS:
Qualcomm Snapdragon 665 Processor
Octa-Core CPU (G6 Platform)
Android 11.0

Memory & Display:
RAM + ROM: 4GB + 64GB / 8GB + 128GB
Standard IPS Anti-Glare LED Screen
16” Vertical Touchscreen

Network & Connectivity:
4G LTE / Wi-Fi / Hotspot
Built-in Bluetooth 5.0
Built-in CarPlay / Android Auto
Support HDMI Video Out


Audio & Sound Features:
Built-in 4745 Radio Module
TDA7388 / 7850 Amplifier
16-Band EQ Adjustment DSP Sound
AHD 1080P Signal Input Support


Multimedia & Performance:
Supports 4K HD Video Playback
Split-Screen Function
Built-in Voice Control
Support for Personalized Themes & Night Mode
Fast Boot with Sleep Mode



[Romer]

I have the older version. Has worked great since I installed it in 2019, but lacks a few features like android auto and allowing to use my phone as a hot spot source.

It is one of the best mods I made. I can get real clear GPS tracking using Gaia, have my music collection loaded to play, can play videos. I can surf the internet if wifi is available (doesnt use phone though as hot spot)

Have been debating this same unit as an upgrade. Will be interested to see how it works for you



[re500]

OEM Camera does not work with this unit. Thats a bummer. Sound is crappy compared to factory stereo.



[kcjaz]

OEM Camera does not work with this unit. Thats a bummer. Sound is crappy compared to factory stereo.

Camera won’t work due to some compatibility issue or you haven’t figured out how to make it work yet?

It’s probably better anyway to replace the ORM low res cameras anyway.



[kcjaz]

I have the older version. Has worked great since I installed it in 2019, but lacks a few features like android auto and allowing to use my phone as a hot spot source.

It is one of the best mods I made. I can get real clear GPS tracking using Gaia, have my music collection loaded to play, can play videos. I can surf the internet if wifi is available (doesnt use phone though as hot spot)

Have been debating this same unit as an upgrade. Will be interested to see how it works for you

Hey @Romer, I have the same PX6 as you and use my phone as a hot spot all the time. It’s an iPhone, but that shouldn’t matter. The only thing it won’t do is auto connect to my phone as a hot spot, I have to manually connect it every time o start the truck.



[Romer]

Hey @Romer, I have the same PX6 as you and use my phone as a hot spot all the time. It’s an iPhone, but that shouldn’t matter. The only thing it won’t do is auto connect to my phone as a hot spot, I have to manually connect it every time o start the truck.

I will have to give that a try



[Romer]

OEM Camera does not work with this unit. Thats a bummer. Sound is crappy compared to factory stereo.

I had to get an adapter box on mine for the camera to work.

Is thee sound glitchy or just not as good?

Does Carplay or Android Auto work well?



[TeCKis300]

OEM Camera does not work with this unit. Thats a bummer. Sound is crappy compared to factory stereo.

The camera integration is a bit complicated. Here's some hints that should help get it working

Tesla Style HU Reverse Wiring

Biting the bullet and going to try and solve this. Could use the hive minds support. SOLVED - See Post #14 This question keeps coming up in various threads and social media channels and I have yet to find a good resource on how to properly integrate this functionality. It's like black...

forum.ih8mud.com



[re500]

I had to get an adapter box on mine for the camera to work.

Is thee sound glitchy or just not as good?

Does Carplay or Android Auto work well?

Sound is not as great as the factory sound. Not glitchy. Just you don't get the purity of music. Good thing is the sub turns on. I have read somewhere the optical port might yield better sound. I'll have to test it out. I got Android13 eventhough the advertised version is Android 11. Will update about Android Auto



[kcjaz]

I will have to give that a try

Sometimes I have to shut off the hot spot on my phone and then turn it back on after the HU boots up. Then search for WiFi networks on the Android unit to connect to the phone. I also only connect my phone via Bluetooth and never the usb cable. A bit of a PITA but I really only want internet when on a road trip or long drive.



[re500]

Ah I tried yesterday and it did not connect. Will try your method tomorrow



[Romer]

How about Android Auto?

On my older unit it wouldnt connect the cameras either and EC Offroad sent me an adapter box that worked perfectly



[re500]

### Checklist

- [x] Verify Audio Output – Test speakers, balance, and equalizer settings
- [x] Calibrate Touchscreen – Ensure proper screen response
- [x] Test Steering Wheel Controls – Configure via head unit settings if needed
- [x] Check Bluetooth
    - [ ] GT6-BYD
    - [ ]
- [x] Verify Navigation & GPS – Open maps and check GPS lock accuracy
- [ ] Test front and side cameras
- [ ] Test Reverse Camera – Ensure it switches automatically in reverse gear
- [ ] Configure CarPlay/Android Auto – Test wired/wireless connection
- [ ] Test Radio
- [ ] Check USB
- [ ] Check SIM card connectivity
- [x] Screen Blackout mode
- [ ] Test out  Toppal Voice
- [x] Subwoofer turn on
- [x] MIC testing
- [ ] Test Emergency buttons
- [x] Test Wifi



[Romer]

so you are saying GPS and Android Auto don't work?



[re500]

Updated. GPS works. Android Auto still not working. I'll raise a support request with this list. The support person was supportive in trying to get the camera working.



[Romer]

Updated. GPS works. Android Auto still not working. I'll raise a support request with this list. The support person was supportive in trying to get the camera working.

Any updates?

You got it from Phoenix and its an Android 13 even though it says 11 on their website?



[Romer]

I called Phoenix Auto to ask about the wireless Android Auot and they said wireless is only Carplay, but Android Auto works with a USB Cable. Have you tried that?



[re500]

It did not work. I couldn't work on it for some time. Tried different cables. I might need to contact helpdesk for it.



[Romer]

It did not work. I couldn't work on it for some time. Tried different cables. I might need to contact helpdesk for it.

Any updates?



[re500]

Got carried away with work stuff. Didn't get time to engage with support.
