Recommended tyre pressure HZJ75 on different surfaces

Discussion in '70-Series Tech' started by Paulrotterdam, Aug 10, 2018.

  1. Paulrotterdam

    Paulrotterdam

    Messages:
    58
    Likes Received:
    38
    Joined:
    Feb 20, 2018
    Location:
    The Netherlands
    I have been looking in the owner manual and on the bfgoodrich site, but can't really get a clear answer on what pressures to run in different conditions. What are your best practices & recommendations?

    • 1996 HZJ75 troopy with an aluminium flip top roof, full camper interior, 80L water tank, additional 120L fuel tank (mostly empty), one spare tyre. Estimated total weight ~3000kg
    • BFGoodrich KO2 T/A 235x85 R16
    Recommended pressures:

    Front tarmac: ?
    Rear tarmac: ?

    Front gravel: ?
    Rear gravel: ?

    Front sand: ?
    Rear sand: ?

    Front mud: ?
    Rear mud: ?

    Front corrugations: ?
    Rear corrugations: ?

  2. TonyP

    TonyP GOLD Star

    Messages:
    4,354
    Likes Received:
    4,938
    Joined:
    May 5, 2014
    Location:
    Utah
  3. FJ73Texas

    FJ73Texas

    Messages:
    1,150
    Media:
    9
    Albums:
    1
    Likes Received:
    942
    Joined:
    Aug 16, 2015
    Location:
    78229
    What is the load range of the tire. E?

  4. LandCruiserPhil

    LandCruiserPhil Peter Pan Syndrome Supporting Vendor

    Messages:
    23,142
    Media:
    55
    Albums:
    3
    Likes Received:
    15,150
    Joined:
    Mar 10, 2004
    Location:
    Scottsdale Arizona
    More tire pressure info than you ever wanted to know. pdf attached
    My experience after reading the linked info is most run too much air.

    For offroad I use a square piece of 1.25" material place it under the center of the width of the tire and let air out until both sides of tires touch. Works well with any size tire and any weight vehicle.


    Attached Files:

    HomerOz and FJ73Texas like this.
  5. FJ73Texas

    FJ73Texas

    Messages:
    1,150
    Media:
    9
    Albums:
    1
    Likes Received:
    942
    Joined:
    Aug 16, 2015
    Location:
    78229
    Thank you for the awesome reference @LandCruiserPhil , especially since I run Toyo Open Country on the FJ73.

    The JATMA and/or tire and rim association yearbooks are great also but I just don't know if we can share pages out of it online?

    Last edited: Aug 10, 2018
  6. coldtaco

    coldtaco

    Messages:
    2,432
    Likes Received:
    953
    Joined:
    Jul 3, 2004
    Location:
    Anchorage, AK
    take chalk and mark across the tire, then drive slowly forward and/or back until the chalk rubs off. Then check for how the marks are and adjust pressure till you get even chalk wear marks.

    SNLC likes this.
  7. Gun Runner 5

    Gun Runner 5 KI4CMQ SILVER Star

    Messages:
    14,487
    Media:
    32
    Likes Received:
    7,506
    Joined:
    Oct 22, 2009
    Location:
    Thomasville, GA
    Here is an alternate method which applies to tire pressure when operating off road. (mud, sand etc.). This is often referred to as the "Redneck Method" and is actually quite simple. When your sidewalls look like this you are at the appropriate pressure. :)

    **In the interest of full disclosure, numerous Bud Lights were harmed to make this post possible.

    Last edited: Aug 10, 2018
    Dprio34, coldtaco and LandCruiserPhil like this.
  8. SNLC

    SNLC OCD Supporting Vendor

    Messages:
    3,666
    Albums:
    1
    Likes Received:
    2,783
    Joined:
    Sep 9, 2004
    Location:
    Cruiser hunting

    This^

    If you want to do it right this is how you do it. Contact patch is what matters not pressure.

    Off-road I like to run 8-12psi unless it is high speed, than it is 12-20psi.


    Cheers

    Dprio34 likes this.
  9. Paulrotterdam

    Paulrotterdam

    Messages:
    58
    Likes Received:
    38
    Joined:
    Feb 20, 2018
    Location:
    The Netherlands
    After searching on Australian fora, people seem to be running 2.7 bar (40psi) front and 3.7bar (55psi) rear for normal road conditions with a fully laden troopy with 235/85/R16 tyres.

    According to Andrew St Piere Whites Four-Wheel drive book:

    Reduce normal pressure for dirt/corrugations by 10-15%

    Reduce normal pressure for rocks by 15-20%

    Reduce normal pressure for sand by 50-60%
