I generated this table to better understand the potential range, payload, and fuel capacity implications of the 250's estimated fuel efficiency (27 mpg).
I did this using four
hypothetical fuel capacities (17, 25, 35 and 50 gallon) and three
hypothetical payload capacities (1500, 1600, 1700 lbs).
Obviously, I do not expect the 250 to come stock with more than 20 gallons (though 25 would be fantastic with over 600 miles of range), and if I had to guess, I'd guess 17 or so (which still affords 460 miles of range), but I wanted to see the implications of larger aux fuel capacity scenarios.
Included for reference are the 80, 100, and 200 series, each with a stock and doubling stock auxiliary fuel capacity scenario.
I included the older series in order to understand what the 250's payload and fuel capacity might be, given its Toyota-estimated fuel efficiency, if it were to benchmark the effective payload after fuel weight, or fuel weight as a percent of payload, of earlier US models.
Ballparking, spitballing, but interesting. No, I do not care about towing.
LC 250 - Hypothetical Fuel Capacity and Payload Scenarios | | | | | | | | | |
| | | | | | | | | |
Series / Yr | Fuel Capacity
(Gallons) | Est. Comb. MPG | Fuel Weight
(Lbs/Gallon) | Total Fuel Weight
(Lbs) | Range
(Miles) | Payload
(Lbs) | Fuel Lbs / Mile of Range | Fuel Weight
Percent of Payload | Effective
Payload
After
Fuel Weight |
80 / 92 | 25.1 | 11 | 6.1 | 153.11 | 276.1 | 1,930.00 | 0.55 | 7.93% | 1,776.89 |
| 50 | 11 | 6.1 | 305 | 550 | 1,930.00 | 0.55 | 15.80% | 1,625.00 |
100 / 2002 | 25.4 | 13 | 6.1 | 154.94 | 330.2 | 1,745.00 | 0.47 | 8.88% | 1,590.06 |
| 50 | 13 | 6.1 | 305 | 650 | 1,745.00 | 0.47 | 17.48% | 1,440.00 |
200 / 2020 | 25.4 | 15 | 6.1 | 154.94 | 381 | 1,570.00 | 0.41 | 9.87% | 1,415.06 |
| 50 | 15 | 6.1 | 305 | 750 | 1,570.00 | 0.41 | 19.43% | 1,265.00 |
250 / 2024 (1700 lb payload) | 17 | 27 | 6.1 | 103.7 | 459 | 1,700.00 | 0.23 | 6.10% | 1,596.30 |
| 25 | 27 | 6.1 | 152.5 | 675 | 1,700.00 | 0.23 | 8.97% | 1,547.50 |
| 35 | 27 | 6.1 | 213.5 | 945 | 1,700.00 | 0.23 | 12.56% | 1,486.50 |
| 50 | 27 | 6.1 | 305 | 1350 | 1,700.00 | 0.23 | 17.94% | 1,395.00 |
250 / 2024 (1600 lb payload) | 17 | 27 | 6.1 | 103.7 | 459 | 1,600.00 | 0.23 | 6.48% | 1,496.30 |
| 25 | 27 | 6.1 | 152.5 | 675 | 1,600.00 | 0.23 | 9.53% | 1,447.50 |
| 35 | 27 | 6.1 | 213.5 | 945 | 1,600.00 | 0.23 | 13.34% | 1,386.50 |
| 50 | 27 | 6.1 | 305 | 1350 | 1,600.00 | 0.23 | 19.06% | 1,295.00 |
250 / 2024 (1500 lb payload) | 17 | 27 | 6.1 | 103.7 | 459 | 1,500.00 | 0.23 | 6.91% | 1,396.30 |
| 25 | 27 | 6.1 | 152.5 | 675 | 1,500.00 | 0.23 | 10.17% | 1,347.50 |
| 35 | 27 | 6.1 | 213.5 | 945 | 1,500.00 | 0.23 | 14.23% | 1,286.50 |
| 50 | 27 | 6.1 | 305 | 1350 | 1,500.00 | 0.23 | 20.33% | 1,195.00 |
