Cape Fear Electronics (1 Viewer)

[Engineer8000]

I used one of these HP oscillators for years. It was a boat anchor.



[Engineer8000]

Those Tek analog scopes will last a lifetime.



[Engineer8000]

I think the oldest piece of test equipment I have now is my Sencore tube tester from the 1960s/1970s.



[Engineer8000]

I pieced this together today to test fj60 intermittent wiper relays. This is the 90A04 version used in the later trucks.



[Engineer8000]

I found a currently manufactured intermittent relay that will work for the FJ60, both versions, it just needs a short adapter harness to plug into the truck harness.



[Engineer8000]

Testing AC amplifiers:



[ToyotaMatt]

sometimes one must reflect on ones self and realize how they got to there " current " place and today's point in there goings on ?


many many fellow members helped me along in my early days this is way way before the oline store , way before my first Reproduction oem part when i was restoring parts mostly

repairing stuff for folks etc ........


RUSS / @Engineer8000 and the needed Pandora BOX he has un-locked on this most amazing quest he is on defys my logic and understanding even close


so ...........


KARMA is KING here !

i have given him this ..

its the worlds ONLY NOS stand alone CB40F users guide and Technician's install instructions mini FSM / EWD


he will now be able to fully RULE the day and help ANUONE CB40F related , in a lock step by the FSM book Fassion

these are NOS oem paper print media jis jazz

here is a TEASE and Easter Egg's on what all he will be able to serve the MUD and Vintage TOYOTA community for the future


the remainder is HIS TOP SECERT SKUNK WORKS world to help him help u .............


kindly matt

Please support my fellow Supporting vendor @Engineer8000 as he continues to break into new and never before uncharted Teq Electronics teritory as i see he both is and does now ..........



ok , enough chatty matty


PHOTOS or it don't exist right ?


BRING IT ON !

long live the CB40F and CB40M


thanks Russ .........



[ToyotaMatt]



[ToyotaMatt]



[ToyotaMatt]



[ToyotaMatt]



[ToyotaMatt]



[Engineer8000]

FJ60 wipers running on a non fj60 intermittent control relay.



[Engineer8000]

CB40M operation on the custom power and speaker harness made to directly connect to the truck radio power and speaker connectors.



[Engineer8000]

90A01 FJ60 wiper relay, this is an amazing little device.



[Engineer8000]

Cape Fear Electronics will be shut down for much of May 2022 for personal stuff. I will be available later in the month. Please leave me a PM or email (cfelectronics@ec.rr.com).



[Engineer8000]

I updated my stereo generator by a few decades.

Stereo composite signal on the SR760, main channel 1 kHz tone (left), 19kHz pilot (center), and suppressed carrier stereo difference signal sidebands at 37kHz and 39kHz (right).



[ToyotaMatt]

this is more up to my speed Russ , that Matrix looks scary ..........



[Engineer8000]

I picked up this really nice Keithley 2015-P DMM recently also. 6-1/2 digits should be enough. In it's new home.



[Bear]

Just read through this entire thread, and must say "Quite impressive." Not only the equipment but the education and experience to operate all this stuff. Thank-you for your analysis and repair of my wiper relay/timer--most appreciated.

We are all very fortunate to have an electronics expert within our group. Thank-you for sharing a bit of the work you do !
