My 77 FJ40 Build (1 Viewer)

davegonz

Keeping it Weird
SILVER Star
Joined
Sep 15, 2004
Messages
9,535
Location
Austin, TX
I recently sold my OM617 powered FJ55 and picked up a 1977 FJ40 from a friend of a friend. My wife was so elated that I sold the pig that she let me buy a 40! Anyway, the 40 is a two owner Texas vehicle with hardly any rust on the tub. The PO had started taking it apart for a full on frame-off resto, but decided to sell since he didn't have time to work on it with a new baby and commuting weekly from Dallas to Austin for work. So, the frame was powder coated, engine/tranny/tcase were rebuilt and painted, and a ton of sheet metal parts/brackets were blasted and powdercoated. He also bought a bunch of new parts for it.

Big thanks to all that have helped me with this: Mauricio (@Spallet ), Lee (@Sea Knight), and Alvaro (@aljollano). Hopefully, I'll get the rest of the stuff over to my house this week!

Here's @Sea Knight deadlifting the tub.


Last edited:

davegonz

Keeping it Weird
SILVER Star
Joined
Sep 15, 2004
Messages
9,535
Location
Austin, TX
Pics of the assembled trucks (43 is Alvaro's and the red 40 is Lee's).



davegonz

Keeping it Weird
SILVER Star
Joined
Sep 15, 2004
Messages
9,535
Location
Austin, TX
Pics of the axles and engine.




davegonz

Keeping it Weird
SILVER Star
Joined
Sep 15, 2004
Messages
9,535
Location
Austin, TX
Powdercoated frame.


davegonz

Keeping it Weird
SILVER Star
Joined
Sep 15, 2004
Messages
9,535
Location
Austin, TX
Pics of the tub.



davegonz

Keeping it Weird
SILVER Star
Joined
Sep 15, 2004
Messages
9,535
Location
Austin, TX
My plan is to get the tub sandblasted, weld up some holes from the fender flares and some tiny holes in the tub where the gas tank sits and then paint it Olive Grey 6H9. I'll post up as I get stuff done. Might be slow, but I'm really digging this truck.


Jdc1

SILVER Star
Joined
Sep 9, 2013
Messages
4,356
Location
Akron, OH
My plan is to get the tub sandblasted, weld up some holes from the fender flares and some tiny holes in the tub where the gas tank sits and then paint it Olive Grey 6H9. I'll post up as I get stuff done. Might be slow, but I'm really digging this truck.
Looks like a great start. Subscribed.


Sea Knight

SILVER Star
Joined
Apr 19, 2006
Messages
2,518
Location
Austin, Tejas and Laurel, Mississippi
I recently sold my OM617 powered FJ55 and picked up a 1977 FJ40 from a friend of a friend. My wife was so elated that I sold the pig that she let me buy a 40! Anyway, the 40 is a two owner Texas vehicle with hardly any rust on the tub. The PO had started taking it apart for a full on frame-off resto, but decided to sell since he didn't have time to work on it with a new baby and commuting weekly from Dallas to Austin for work. So, the frame was powder coated, engine/tranny/tcase were rebuilt and painted, and a ton of sheet metal parts/brackets were blasted and powdercoated. He also bought a bunch of new parts for it.

Big thanks to all that have helped me with this Mauricio (@Spallet ), Lee (@Sea Knight), and Alvaro (@aljollano). Hopefully, I'll get the rest of the stuff over to my house this week!

Great score Dave. Now get after it. :beer:



TheHardWay

Ain't as easy as it looks
SILVER Star
Joined
Dec 29, 2013
Messages
1,723
Location
Las Cruces, NM
All right, I'll bite - what does 6H9 Olive Grey look like?


davegonz

Keeping it Weird
SILVER Star
Joined
Sep 15, 2004
Messages
9,535
Location
Austin, TX
Like TMarx's 40 and Scrapdaddy's pig.

1131-jpg.392998


img_2889-jpg.1077832


DPV7070

ForceFed40
SILVER Star
Joined
Jun 13, 2010
Messages
950
Location
Vestavia, AL
Wait, so Hamp is gone??? Either way this is going to be really nice. You've got a great point from which to start. Can't wait to see the progress. Sub'd


davegonz

Keeping it Weird
SILVER Star
Joined
Sep 15, 2004
Messages
9,535
Location
Austin, TX
Almost gone. Buyer will pick it up next week.

Today, we moved the axles/engine and tranny assembly and two large crates of parts. My slightly sloping driveway sure didn't help. :(


Last edited:

davegonz

Keeping it Weird
SILVER Star
Joined
Sep 15, 2004
Messages
9,535
Location
Austin, TX
Got some help from a friend (thanks Eric) this morning and moved the axles under the frame. Just can't find the damn shackles. Might have to buy some.


davegonz

Keeping it Weird
SILVER Star
Joined
Sep 15, 2004
Messages
9,535
Location
Austin, TX
Getting stuff sorted. Check out all the powder coated stuff. There's more of them that I haven't gotten to.


davegonz

Keeping it Weird
SILVER Star
Joined
Sep 15, 2004
Messages
9,535
Location
Austin, TX
Someone jokingly called it the Ikea truck. :)


mmw68

CruiserCrap.com - pimping crap for your cruiser!
Supporting Vendor
Joined
Dec 13, 2004
Messages
3,496
Location
Austin, Texas
Website
store.cruisercrap.com
Someone jokingly called it the Ikea truck. :)
Yeah... But it will last so much longer then IKEA furniture. Can't wait too see the build.,
