99 LC rear axle assembly with factory locker (1 Viewer)

Joined
Jan 5, 2017
Messages
110
Location
Maryland
I have been offered a rear axle assembly from a 99 LC with the factory locker and all the hardware. I have a 2001. Will my 01 have all of the correct connectors to make the swap? How many banana's is the swap in terms of difficulty?


gregnash

Anal Retentive Analyst
SILVER Star
Joined
Nov 3, 2011
Messages
12,194
Location
Carson City, NV
Connectors as in for the electronics for the locker or are you talking like mounting points, brake lines and whatnot?
I believe the gearing didn't change until 2003 but I could be wrong, outside of that everything else should bolt right up, at most you might have to do some wiring yourself to have the locker function, but the knockout for the switch is there.


jLB

May be in need of a 12 step LC/LX program.
SILVER Star
Joined
Dec 2, 2014
Messages
2,518
I’m pretty sure @savirc documented this somewhere build thread:


From what I remember:
A 3rd party wiring harness
A Slee control board
Brake lines were a little different between VSC/ATRAC models and non-VSC/ATRAC models

Last edited:

JunkCrzr89

Competent Ignoramoose
SILVER Star
Joined
Jul 21, 2019
Messages
2,621
Location
Colorado
You have none of the electrical components - this is not plug and play for an 01. You also need to remove the brake lines from the 99 axle and swap yours over because A-TRAC/VSC.
