BJ-74 fuel feed pump inlet screen (1 Viewer)

[John Galt]

The fuel feed pump on the 13B-T engine in the BJ-74 has a screen in the banjo bolt on the fuel inlet.

Can someone post a fuel feed pump diagram showing this screen and a part number?



[roscoFJ73]

You can use a fliter screen off other B or H engines 22529-67010, all have the same part number.



[John Galt]

Thank you very much.
