FJ40 Engine Pictures Thread

[thecrazygreek]

CCOT Pic

Heres the CCOT pic someone linked to...



[Coolerman]

Stock 1F with a different theme...



[nc_fjizzle]

Freshly rebuilt 2F with less than 200 miles on it...



[Trollhole]

These are few friends cruisers.

72-73 I think. Unmolested still has the factory paint.

77 Resto a friend did

My old 76 2f prior to BG2. Ignore the way the PCV Valve was connected it was so wrong.

What looks to be a 73-74 Only reason I saved the pic was to show have the dealers installed the Clardy A/C unit.

ANother friends resto in a FJ45



[amraspalantir]

guys you know any store selling those "stainless steel" radiator hoses?
they add pizzaz even to a stock looking engine.



[Trollhole]

Jegs or summit will have the covers. That is what most of them are. Do a search for Spectre



[american psycho]

GEN Spec 1984 2F with FJ60 P/S & Alt Placement

I liked high placement of alt & P/S pump,and I really like the lack of spaghetti.



[tlc_4play]

Here's my 2F

Before

After rebuild

Dropped into chassis



[FJ40_owner]

Performance upgrade.

V12 Jaguar mated to stock 4 speed.

Why would you want to do this?



[jfz80]

and no pics of Big Gay post painting party?


heres mine

2F built to stock specs
3FE exhaust manifolds
GM ambulance altenator
in limbo waiting to be fired up



[amraspalantir]

thanks trollhole for the input.
jfz80.....what type is that air cleaner your using?i read the brand "SPECTER"
that seems a nice substitute for the original aircleaner.

nice engine pics guys.



[jagota]

Why would you want to do this?

I had my reasons. Of coarse some would say the same about a 350 with an automatic.



[POTATO LAUNCHER]

First post. Got a camera for Christmas, Thank you my loving Wife.

1. 73 fj40 fresh 355. Less than 500 miles.



[amraspalantir]

potato launcher......what do you call that type of air cleaner?
nice engine there.



[IDave]

My F135...in action.





(Gotta get a few more views of that...)



[pappy]

My F135...in action.

(Gotta get a few more views of that...)

That is too cool.



[Trollhole]

While we are showing some crazy combinations I'll throw in a few I have collected over the years online.

The engine was too damn big for a whole engine bay shot. But trust me this was in a 40.



[Bennett]

Cummins 3.3 Turbo and a OM 617 Mercedes Turbo



[POTATO LAUNCHER]

Amrasplantir, not sure witch air cleaner you're asking about. Large is 14" x 4" K&N, small filters are for crankcase venting. Old set of circletrack valvecovers I use on race car. Front has a larger opening in the bottom, no funnel required for oil change, just dump it in.



[jfz80]

thanks trollhole for the input.
jfz80.....what type is that air cleaner your using?i read the brand "SPECTER"
that seems a nice substitute for the original aircleaner.

Just a 3'' paper filter from the ricer aisle in the auto parts store.
filter $15
elbows 45 and a 90 $5.99 each
fits the stock aisin carb perfectly
