What have you done to your 100 Series this week?

This site may earn a commission from merchant affiliate
links, including eBay, Amazon, Skimlinks, and others.

Added a 50" light bar + Rock lights!

I have a "light bar drop down" for my Gamiviti rack, but I decided I didn't want to have to remove the fairing every time I wanted to use the light bar, so I opted for a slim single-row 50" light bar on top of the rack. I had to weld on my own custom brackets, but I think it came out pretty good. It is an combo flood/driving light I found on Ebay. It is far enough forward that I can still throw my roof top box up there, and far enough back that it doesn't shine on the hood. The thing is SUPER BRIGHT!

For the rock lights, I installed LUX Monsters. Went with 4 on each side for a total of 8. Installed by running all of the wiring through the frame rails. Each light comes with 10' of cord so I daisy chained them together and had plenty of wire. The LED's are encased inside a rock-hard resin with a super strong magnet on the back, so you can literally slap them on just about any flat surface and they are solid. The magnets are so strong I actually cut myself trying to re-position one of them... the light snapped into place on the frame and pinched some skin. All in all the install was very easy if you are handy with a soldering iron and cable fishing tool. Really happy with the light output, but ordering from LUX was a PITA. From my experience, they have 0 customer service. Had to issue a claim on PayPal to get my items shipped. But so far the product is great, so I'm still a happy camper.

Everything is hooked up to my Switch-Pros sp9100. I have the device programmed so the rock lights turn on when I hit the unlock button or open a door. It's still light out on the west coast, but I'll snap some night pics and post a bit later.







Last edited:
TheForger said:
Did the "street sign" mod to my mirror the other day...Much better visibility when the glass is in shards I can see every angle now, they're basically like tow mirrors. Highly recommend this:bang:

View attachment 1662829
Click to expand...

cmck said:
Nice Mod, how much ? :rofl: (don’t answer that)
Click to expand...
Hahah I'm an idiot and just wasn't paying attention to the road and side swiped it at about 40mph. Luckily it didn't actually break the mirror assembly, just the glass when it folded inward. Because of that it only cost me about $55 for the replacement glass as opposed to the ~$200 for the entire mirror assembly.

For anyone else who is curious the passenger side mirror glass pn is 87931-60801; the drivers side glass is 87961-60840. I cross-checked these pn's with later years and all the websites say it's compatible with years '03-'07 as well, but purchase at your own risk. Good as new now!





2001LC said:
@dace voit Pictures?
Did the new face plate for HVAC cooler come with door or did you need to order two parts, part (s) #?
Click to expand...

Two separate covers needed to be purchased. "Cooler Cover #1, 88891-60040", which is the small filter cover and "Cooler Cover #2, 88891-60050", which is the cover to the airbox itself.

I thought that I got a couple of pix of the cover #1 but I didn't. :doh:

Some side-by-side shots of the light output on the 50" light bar.

Low Beams:

IMG_20180325_200005 (1).webp


High Beams:



Light Bar + High Beams:



Hard to tell the difference in some of these shots, but the light bar shoots much farther than the high beams and also floods the periphery.

Hood lifts for both trucks. A snow shovel makes a fine assistant.

@n55luvr Where did you get the gas tank skid?

It's OEM, part number 77606-60120 and was about $350 shipped.

Took 2 hours start to finish. Could probably do it half the time if I ever had to do the job again.
