I’m keeping my mouth shut
Wits End Turbo Owners
- Thread starter spyduh
- Start date
This site may earn a commission from merchant affiliate
links, including eBay, Amazon, Skimlinks, and others.
- Status
I’m keeping my mouth shut
It's in the plans in my head... Big injectors, 20psi, intercooler, piggy back etc.
- Joined
- Sep 9, 2004
- Threads
- 184
- Messages
- 13,097
- Location
- Boise - Idaho
- Website
- www.snlandcruisers.com
if you really want to talk about turbo 1FZ’s just shoot me a message. I don’t want to muddy the water about the turbo kit that is for sale and what it sounds like you might want.
Thanks for the solid info.
Cheers
- Joined
- Jul 8, 2013
- Threads
- 64
- Messages
- 3,045
- Location
- New South Wales, Australia
- Website
- www.completecruisers.com.au
I can guarantee you that a turbo and intercooled 1FZ at about 8 lbs of boost with front driveshaft pulled (and CDL locked) will do burnouts to your heart's content.I can get a/my 1FZ to cruise just fine and pull passes just fine by simply tuning it.
I would want more. The 5vz did burnouts!
Cheers
A gturboed and fuelled 1HDT will also do the same thing for the record
I miss them both
but life moves on and sometimes that means cruisers do too.
- Thread starter
- #169
I can guarantee you that a turbo and intercooled 1FZ at about 8 lbs of boost with front driveshaft pulled (and CDL locked) will do burnouts to your heart's content.
A gturboed and fuelled 1HDT will also do the same thing for the record
I miss them both
My turbo from Joey with Rear Wheel drive (Part time), stock boost no IC or meth, 7100lbs (not fully loaded), with 35s on 4.88s was chirping tires on 2nd gear. I did not do a CDL locked burnout but I know it will do it! It's got a stupid amount of power in RWD. 4wd def feels a lot faster but nothing like RWD and the Turbo together. I still say to this day I need a lighter 80 with stock tires and a turbo kit and RWD. That be a blast to daily!
I have seen 7 PSI consistently, especially pulling hills in the Sierra's. Under a hard acceleration, it will blip over 7 PSI to 7.2, 7.3, but the waste gate quickly corrects that back down. I put that down to a bit of a delayed response in the waste gate. I am running the 14 in 1 gauge setup from JRP.
Truck is down right now, sheared off all of the d-side rear axle hub studs on the Rubicon a few weeks back. in the process of upgrading to M10 hardware. Turbo did not do that, as it does not develop any boost in 4 Low crawling. That was 37" tires, a ton of gear, 4.88 diff gears, 3.11:1 transfer case gears, and some really good traction on really big rocks. Had fun limping it out of there and back to South Lake Tahoe for a bolt fix.
Edit: I should add that the Lambda on the wide band is always at 1 or below. I have never seen it get lean, but do not watch it religiously. Makes me wonder if there is a bit of headroom in the stock system for a bit more boost... Dangerous thinking there.
Last edited:
This is good info, thx for that. If you have the time, please post up a short video.
Coupla things:
1) Changed the stock new gen blue hub fluid to 20k from stock. Brownish goo came out. put 50ml of 20k in. Temps are 8-10* cooler on average. Otherwise 20k old cooling system. Stoked on that.
2) Oil feed line at top of turbo worked itself "hand tight". Happened to notice it was loose and pulled the feed line, re-tightened the insert into the turbo, then reattached feed line. I had checked this multiple times but recommend you all keep an eye on yours as well. Looked like the thread sealant had cooked out of the threads loosening it up. Wonder if tight temp thread sealant is a thing.
3) I have an obnoxious rattle under acceleration. Can't find it. Probably not turbo related but its going to drive me insane.
Love this turbo so much. Its such a game changer for the 80.
1) Changed the stock new gen blue hub fluid to 20k from stock. Brownish goo came out. put 50ml of 20k in. Temps are 8-10* cooler on average. Otherwise 20k old cooling system. Stoked on that.
2) Oil feed line at top of turbo worked itself "hand tight". Happened to notice it was loose and pulled the feed line, re-tightened the insert into the turbo, then reattached feed line. I had checked this multiple times but recommend you all keep an eye on yours as well. Looked like the thread sealant had cooked out of the threads loosening it up. Wonder if tight temp thread sealant is a thing.
3) I have an obnoxious rattle under acceleration. Can't find it. Probably not turbo related but its going to drive me insane.
Love this turbo so much. Its such a game changer for the 80.
This was the mount that my brother and I came up with. Post #218
80 Series Aftermarket Gauge Choices & Mounting Options
I too was very intrigued with this route however, I was less than keen on having multiple screens and such scattered around my interior so I resorted to the 52mm gauge route instead. I feel they will provide a much less intrusive look. My $0.02! Cheers! It can be run to 52mm gauges or a...
forum.ih8mud.com
that looks great. I ordered the autometer 3 gauge universal and will make a simalar mount for it. Going for boost/afr, oil pressure/ temp and water temp/voltage from innovate.This was the mount that my brother and I came up with. Post #218
80 Series Aftermarket Gauge Choices & Mounting Options
I too was very intrigued with this route however, I was less than keen on having multiple screens and such scattered around my interior so I resorted to the 52mm gauge route instead. I feel they will provide a much less intrusive look. My $0.02! Cheers! It can be run to 52mm gauges or a...
6.2 is fine. It is totally possible your cats are old and slightly restrictive. This is not rocket surgery
The plan was to be overly safe rather than overly risky.
The plan was to be overly safe rather than overly risky.True. I come from turbo Subaru world and am used to running catless setups.6.2 is fine. It is totally possible your cats are old and slightly restrictive. This is not rocket surgery
First cat is recently replaced. Second is original. Might be time to replace just for mo boost if it'd help. Also wasn't posting to complain, just to give a comparison point to others.
Yeah catless would reduce the restriction and possibly make more boost but the system is designed to be as fool proof as possible with as close to the stock setup as possible and not require an electronic boost controller.
