Your garage background shots are suspiciously clean. I have a feeling you know what you are doing, and take your time to do things right the first time. Good work on all that suspension upgrade stuff, I can't wait to see the motor and trans swap.
Cheers!

Joined
Jun 17, 2016
Messages
434
Location
Seattle Area
Also dropped the front panhard and new bushings off at the shop to be pressed ... No way was that working out in a home garage with a bench vice and a sledge hammer. :hillbilly:
Hey Feldrian, nice work on your axle. I'm thinking of doing the same next year. I'm local to you, who did you use to replace the bushings? Thanks in advance

Joined
Jun 19, 2020
Messages
130
Location
Lynnwood, WA
Productive day yesterday. Front end is back under the truck. Installed:
  1. Delta 4" arms w/ OEM bushings
  2. Delta sway bar drops (didn't replace the ball joints - they looked fine)
  3. New OEM sway bar rubber and fasteners
  4. New 555 tie rod and drag link ends
  5. New Koyo trunnion bearings
  6. ARB air locker w/ new 4.56 gears
  7. New axle seals
  8. New knuckle studs, cones and fasteners
  9. RCV 30 spline axles and birfs
  10. New ABS tone rings (which I looked like an idiot trying to install)
  11. New spindles w/ roller bearings
  12. New Koyo bearings wheel bearings, seals and wipers
  13. DBA T3 rotors
  14. New OEM hub studs (which were a huge pita)
  15. New hub stud cones, washers and nuts
  16. New axle clips and dust covers
  17. Slee braided SS brake lines
  18. New OEM calipers
  19. DBA 610 pads w/ new OEM shims and springs
  20. Extended the diff breather
  21. New OEM tail lights w/ LED reverse bulbs
Managed to shear hub studs a couple of times, despite being careful. Going check the calibration on my torque wrench to be sure I don't have an issue there. Also stripped two caliper bolts (with a different torque wrench) - all of the shears/ strips happened on the driver's side so I'm wondering if all of this was messed up previously and the caliper bolts had been cross threaded. One of the caliper bolts stripped at about 30 lb-ft, the other at about 75 ft-lb.

Still waiting on a few parts before I can turn the truck around in the garage and tackle the rear - Icon shocks and springs, Dobinson's steering stabilizer and the panhard bar I dropped off to have the new bushings pressed.

Hoping I don't shear/ strip as many fasteners on the rear :rolleyes:


Joined
Jun 19, 2020
Messages
130
Location
Lynnwood, WA
Order placed for a M12x1.25 Heli-Coil master set so I can repair the caliper to knuckle threads on the drivers side. Rookie running a Heli-Coil for the first time - Good thing it's not something important like my brakes. :ninja:

Joined
Jun 9, 2020
Messages
45
Location
Seattle
Kinda think I need to come by. I’ll bring Rose our 97 LX450. I have a feeling you could teach me quite a bit. We are in Maple Valley and we’ve had ours about 6 months. Not near the build you have.

Great work

Joined
Jun 19, 2020
Messages
130
Location
Lynnwood, WA
Kinda think I need to come by. I’ll bring Rose our 97 LX450. I have a feeling you could teach me quite a bit. We are in Maple Valley and we’ve had ours about 6 months. Not near the build you have.

Great work
Happy to help!

My build is in pieces though. I don't get to claim victory until it moves under it's own power again, without the deafening rod knock.

Joined
Jun 19, 2020
Messages
130
Location
Lynnwood, WA
Time to return it and get the right stuff. Thanks for the heads up on cost.
I decided to install the coils since I had them anyway and absolute worst case I'd be out $150 for a new knuckle. The process was WAY easier than I was expecting. Took about 45 min all up for both coils, including me messing up the first insert. Installed the caliper and torqued to 90 lb-ft no problem.

Had to run the tap on an extension, which wasn't ideal but still managed to tap the hole plumb.


Shiny new coil.
