Cerakote is done now I need to finish machining the fuel blocks.
bobm
WTF, WTF, WTF!!!!
Looking awesome
- Thread starter
- #67
Thank you buddy!Looking awesome
Started on the fuel blocks, still have some stuff to figure out but it's going good so far
- Thread starter
- #68
Just need to make a few more parts then I can start working on the plumbing...
- Thread starter
- #69
Started plumbing, had to modify a tube bender to make some of these lines but I'm happy so far.
- Thread starter
- #70
Went back to the shop after dinner and finished the last four...
Right arm
question…what are the outside tubes feeding. The injectors I can see are on the inside…
question…what are the outside tubes feeding. The injectors I can see are on the inside…
- Thread starter
- #72
I’ll be using the Holley Terminator X engine management system to control this mess and it has an on-board one-bar MAP sensor (Manifold Absolute Pressure) that is required for it to do its job.
I had two choices to provide the reference it wants 1) try to hide it under the manifold with some plastic line or 2) embrace it and try to make it look cool on the outside. I bought braded lines and black fittings and stainless ¼” hard line with stainless fittings to run the fuel and vacuum and originally planned to use one of them once I got to this point. After seeing the gold stacks I felt like copper lines and brass fittings was going to look better on this project so that’s what we got.
I’ll mark everything and strip this all back apart so I can make the rest of the junk and get it Cerakoted before final assembly but I kind of like the direction its going so far.
Ok now I understand, the 510 guys had similar MAP issues doing individual throttle bodies on a side-draft manifold.
I like your solution.
I like your solution.
- Thread starter
- #74
Not only do you need individual cylinder reference with a stack style injector but is has to be under the butterfly so it’s easy to run out of space and options quickly, I spent more time on the split fuel block and thinking about how to plumb all this than I want to admit.
bobm
WTF, WTF, WTF!!!!
That's some
crazy bending. Looks great
.
crazy bending. Looks great .
- Thread starter
- #76
Time to put the tube benders away for a bit and try to come up with something for the throttle linkage, I need to cut the throttle shafts and add some flexible bellows so I'm not sure if the old sprint car stuff will work...
bobm
WTF, WTF, WTF!!!!
I would Clear coat Copper n Brass instead of Cerrakote
bobm
WTF, WTF, WTF!!!!
bobm
WTF, WTF, WTF!!!!
Not to throw wrench in you plans! What about 1 main fuel rail down the center with feeds to injectors off the main?? Would be cleaner.
- Thread starter
- #80
Yes I could have made this look like an LS engine and saved a bunch of time and money..
But you know me better than that...
