These 16" wheels will work and they look great, but...

[Ride Fly]

OE (Series 659) Overstock

U.S. Wheel’s beginnings go back to the early 60’s with the family owned metal stamping facility. In the 80’s we branched off with a small back alley shop and began manufacturing completed steel wheels. Now that we’re entering the 21st century we have steadily and consistently grown to become one...

www.uswheel.com

But the outer measurements for the clips for the hubcaps are 11 5/8". There's no way to get the OEM Toyota hubcaps on these is there?? I'm looking for 16" wheels that are wider than the 5.5" that the City Racers have. 7" would be preferable but I'd go as narrow as 6". 5.5" on 255/85/16 (33x10x16) is not where I want to live! Danke schön!



[studawg]

I dont know about adding clips to them, but I ran a set of these on my FJ62. They are also available in 16x7 but it looks like they are on backorder...

16x6 Smoothie Primer | 6x5.5" bolt | 4" backspace - https://cokertire.com/catalog/product/view/id/70288/s/16x6-smoothie-primer-6x5-5-bolt-4-backspace-12-660604a/category/32632/



[jim land]

Cut the inner part of the cap made for those wheels and weld ( or glue or srew) it to the back of the toyota hubcaps ,



[nabbasi]

City racer sells just the clips. Might be possible to drill and bolt the clips on.

I’ve got the slightly more narrow 235/85R16 on my cityracer wheels.



[Ride Fly]

Cut the inner part of the cap made for those wheels and weld ( or glue or srew) it to the back of the toyota hubcaps ,

Not able to picture what you're recommending. Are you saying cut off the flange on the wheel? The "nubs" are where the hubs attach to I believe. Cut the entire flange where the 4 nubs reside?



[Greek Cruiserhead]

OE (Series 659) Overstock

U.S. Wheel’s beginnings go back to the early 60’s with the family owned metal stamping facility. In the 80’s we branched off with a small back alley shop and began manufacturing completed steel wheels. Now that we’re entering the 21st century we have steadily and consistently grown to become one...

www.uswheel.com

But the outer measurements for the clips for the hubcaps are 11 5/8". There's no way to get the OEM Toyota hubcaps on these is there?? I'm looking for 16" wheels that are wider than the 5.5" that the City Racers have. 7" would be preferable but I'd go as narrow as 6". 5.5" on 255/85/16 (33x10x16) is not where I want to live! Danke schön!

An Aussie Mudder suggested this:

Landcruiser Wheels Australia | OEM Steel Rims for 4x4s – BCI Wheels

Shop OEM-style Landcruiser wheels for FJ40, FJ45 and more. Our Landcruiser and Defender wheels are ISO-certified, built tough for 4WDs, and delivered Australia-wide.

www.bciwheels.com.au

PS. Got a set of four for my 40-Series, quality as expected!



[Chungas Revenge]

Fifteen 52 wheels. Clips added IOT run the OE hubcap. Installation by RCLC @Jdc1. Three colors available. I went with the 16” flavor. Running a 285-75 R16 Tire.

Edit. Grey is currently sold out. Black is available.

Analog HD _ Peak Grey | Off-Road Truck Wheels | 52OFFROAD

Fifteen52's Analog HD takes the classic steel wheel design and adds a modern touch, casting it in lighter aluminum and updating the classic style to fit a wide range of modern and vintage off-trucks. Available in 16" and 17" with select bolt patterns like: 6x139.7, 5x127 and 5x150. Also...

fifteen52.com



[pb4ugo]

Not able to picture what you're recommending. Are you saying cut off the flange on the wheel? The "nubs" are where the hubs attach to I believe. Cut the entire flange where the 4 nubs reside?View attachment 4176985

Several years ago a member found a set of cheap hub caps that fit the aftermarket wheel nubs, then adapted those hub caps to fit inside the stock Toyota hub cap. You would have to search for the post here or on the internet.



[pb4ugo]

Here ya go. It's post #57 in this thread. It looks like @luckynb hasn't been here for couple of years.

Build Post in thread 'LuckyNB 77 FJ40 - 7 Year Journey'

Oct 26, 2019

Ok, here goes.. OEM hub caps fused to baby moon caps that fit aftermarket steel wheels.
I really wanted to run OEM caps, but also wanted to run a larger tire, so needed a non-OEM wheel.
I was prepared to run stock looking steel wheel without caps, but thought I'd give this a shot.

If you are opposed to cold-fusion, stop reading now, otherwise read on.

I got the wheels and hubcaps from Summit

Wheel Vintiques 12 Series Smoothie Wheels
Part # 12-580604 - 15x8, 6 on 5.5 - $80.99 each (I bought 5)

Pardon Our Interruption

Wheel Vintiques Center Caps 1009 baby...

• luckynb

•



[71FFJ40]

Modifying those Moon caps and adhering them to OEM caps works well.Pretty easy to do and they stay on-no issues.Have approximately 500 miles on a set with the Vintiques and they have not moved.



[jim land]

Not able to picture what you're recommending. Are you saying cut off the flange on the wheel? The "nubs" are where the hubs attach to I believe. Cut the entire flange where the 4 nubs reside?View attachment 4176985

No , just modify the cap not the wheels
Can't find the thread that shows how to do it , but post #20 of this thread show a modified hubcap to fit on custom wheels

Thread '66' R2.8 1BADRESTO'

Nov 9, 2018

Ok ... here we go again, but this time more emphasis on Resto

NO rust 1966 FJ40 from Alaska

PLan;
Very traditional exterior, awesome drivetrain, and bad A!! interior
Colour - Toyota Calvary blue, traditional white hard top, white front grill/bezel and powder coated custom 16" white smoothie wheels with 33's
OME 2" suspension with Fox shocks (again)
Crate Cummins R2.8 Diesel engine, GM NV4500 5 speed tranny, Toyota split case
and lots of cool crap

so far ....
Stripped down to bare steel and epoxied...

• Sheck44
• Replies: 186
• Forum: 40- / 55-Series Tech

•



[jim land]

Here ya go. It's post #57 in this thread. It looks like @luckynb hasn't been here for couple of years.

Build Post in thread 'LuckyNB 77 FJ40 - 7 Year Journey'

Oct 26, 2019

Ok, here goes.. OEM hub caps fused to baby moon caps that fit aftermarket steel wheels.
I really wanted to run OEM caps, but also wanted to run a larger tire, so needed a non-OEM wheel.
I was prepared to run stock looking steel wheel without caps, but thought I'd give this a shot.

If you are opposed to cold-fusion, stop reading now, otherwise read on.

I got the wheels and hubcaps from Summit

Wheel Vintiques 12 Series Smoothie Wheels
Part # 12-580604 - 15x8, 6 on 5.5 - $80.99 each (I bought 5)

Pardon Our Interruption

Wheel Vintiques Center Caps 1009 baby...

• luckynb

•

That is what im talking about



[Ride Fly]

Alright fellas! First and foremost, I want to thank everyone for their input! Did a lot of research and helped formed my decision to go with an aluminum wheel that is wider than 6". Actually settled on 7" to keep the narrow profile without the tires bulging out at the sidewall. I have it narrowed down to the Fifteen52 Analogs that Chungas posted a pic of and the Nomad 504 Field. Both are made of aluminum: the Analogs being cast aluminum, and the 504s being Formlite, which is a hybrid cast/forged wheel. The 504s have Nomad labeled look-a-like hubs but that's not a deal breaker. The Analogs require drilling and tapping, and requires purchase of tabs and hubs. But I can get OEM hubs. Price for each option is similar.

All that said, the 504s lead due ti the Formlite process. That overrides the negatives.



[Ride Fly]

Update on my wheels and tires:

I've been waiting for Nomad to restock the 504 Fields in satin black, 16"x7". They are still a couple weeks out. However, they have 16"x8" wide wheels available. Should wait for the 7" or go 8"? Is the extra inch of width going to make it look different? I thought it might "flatten" the sidewall a bit, but as long as it doesn't lose any diameter height, I'd be fine with it.



[onemanarmy]

FJ40s deserve narrow wheels....



[pb4ugo]

I currently run stk steelies with a 35 and 33-10.50's and they're OK. I've run 15x8 wheels in the past with 36-12.50's and will likely be running 15x8's with a 35-12.50 with about a 3.75" or 3.5" offset in the future. In my experience, The side walls usually are slightly proud of the 1/4 panel and tend to tuck inside the fenderwell on compression. This seems to help keep the 1/4 panel out of harms way in certain situations. The added width adds to stability. The tread tends to stay under the fenderwell. I would not run 10.50's with an 8" wheel. I like to squeeze the bead on the wheel. Your results may be different. I run a 4" lift.
