Front recovery points on GX460 (2010-2013)

[sheptastic]

At $300, I stopped looking and didn't realize that was just for one. I'd rather put that toward a bumper. That was the only listing I came across searching for the ARB points. There have been some changes in availability from Guide to GX 460 Builds and Aftermarket Products - https://forum.ih8mud.com/threads/guide-to-gx-460-builds-and-aftermarket-products.1168653/.

I couldn't find those overpriced points sold by ARB or Ironman, just Metal Tech. It didn't look like Trail Tailor has any available (or ever did?).

The only other options I came across were:

GX460/5th gen 4runner Recovery Points

*please read the description, these are shipped raw steel. The points in the photos were spray painted prior to install* Designed and manufactured in Houston Texas, the Treaty Oak Offroad recovery points are the only heavy duty recovery points available in the US. Your factory tie down points...

www.treatyoakoffroad.com

Recovery points LC150 / GX460

Updated Design that allows use with soft shackles! Recovery points for: Land Cruiser Prado 150 Lexus GX 460 4Runner 5gen. Additional front recovery points. Direct fit in existing holes. 2 x 12mm steel front tow points, 6 x bolts, 8 x flat washers, 4 x spring washers, 2 x Teflon nuts...

bison-gear.com

Amazon product ASIN B07WGJ4ZRX
They all seem similar. Bison Gear is the cheapest, but shipping may be more since it's international.



[Washingtontaco]

With those flat plate recovery points insure you rig a bridle and mitigate side loading.

The ones that use to be available from Ironman were low quality. I actually cracked a weld on one installing then when I first bought my GX. I had so many problems with Ironman parts that I wouldn't consider them direct bolt parts and have since replaced all my Ironman parts.



[sheptastic]

Proper recovery training is warranted as well. Good to know about the Ironman gear. And, certainly don't take any of my information as a recommendation. I don't know anything - I've just been spending every waking hour since I got my GX researching available options and that's what I've found for front recovery points. Figured someone may find it useful.



[re_guderian]

I have these on my 470. They also work on a 460. They are super-beefy and can accommodate side loading, but are not KDSS compatible. I think they are beefier than the Bison points as they really surround the framerail on all sides and have like 6-7 bolts that hold them on (the Bison points only have 3). The steel is 1/4" thick but it's two layers in some areas so you get a 1/2" thick section. They are raw steel but I painted mine in Farmall Red. The best thing as they are only $125!

2003-2024 4Runner Lower Link Mount Reinforcement (LLS)

Upgrade your stock links with these 3/16" plate and self aligning EIMKEITH lower mount reinforcements.*Welding required

www.srqfabrications.com

Aren't all 460's equipped with KDSS?



[Washingtontaco]

Aren't all 460's equipped with KDSS?

Yes



[Rednexus]

Yes

My bad, I thought that some of the base models perhaps did not have KDSS. Either way, they are a good option for 470 folks and I have been pleased with mine.



[BigSwede]

The factory recovery points are fine as long as you don't allow the welds to rust.



[Acrad]

Limited options when I added them to mine back in early '17 so put these ones from Australia on

Build - GX460 Build Thread

forum.ih8mud.com



[THEOZMAN]

I have found honestly the best recovery point on the market of the the 460.

Shop | Apex Overland | Off-Road Part Accessories

Shop for all things for your overland rig. Roof racks, storage solutions, bumpers, recovery gear, suspension, air, fuel and power solutions. Camping gear, front recovery points, lighting, Armor, skids plates, sliders and more!

www.apexoverland.com

APEX Overland people are incredibly nice and extremely helpful! I went to their shop in NC to have BMC and KDSS spacers installed since I didn't want to risk braking the bolts. I held these in hand and man, they are extremely stout and well made.

with 3 frame and 1 radiator support they can handle side load just fine.

Only reason I don't have them on is because I am too lazy to take my bumper and winch mount off since you have to insert a dual welded nut plate through the front of the frame for the 2 bolts above the KDSS bar.



[r2m]

I have found honestly the best recovery point on the market of the the 460.

Shop | Apex Overland | Off-Road Part Accessories

Shop for all things for your overland rig. Roof racks, storage solutions, bumpers, recovery gear, suspension, air, fuel and power solutions. Camping gear, front recovery points, lighting, Armor, skids plates, sliders and more!

www.apexoverland.com

APEX Overland people are incredibly nice and extremely helpful! I went to their shop in NC to have BMC and KDSS spacers installed since I didn't want to risk braking the bolts. I held these in hand and man, they are extremely stout and well made.

with 3 frame and 1 radiator support they can handle side load just fine.

Only reason I don't have them on is because I am too lazy to take my bumper and winch mount off since you have to insert a dual welded nut plate through the front of the frame for the 2 bolts above the KDSS bar.

View attachment 2966634

That looks like it can handle some serious lateral loads!



[sheptastic]

Those do look good. I think I missed the link for the "5th gen 4Runner KDSS Recovery points" under "Does NOT work with KDSS equipped vehicles". I had looked at Apex a while ago, but didn't realize they had a set that would work on the 460.



[re_guderian]

Has anyone used these in an actual recovery without mangling the s#!t out of your plastic bumper cover? The 460 bumper cover hangs down much lower than the 4Runner one.



[r2m]

The folks that don't have any interest in getting steel bumpers usually trim both the front and rear bumpers up several inches for ground clearance.
If trimmed, it may not be an issue. But that all depends upon what angles one is pulling at too!
I could easily see an instance where the nose (or rear) is dropped in a hole or gully enough that regardless the bumper, that recovery line will be pulling upward into the bumper.



[Bang Bang]

The factory recovery points are fine as long as you don't allow the welds to rust.

Have you used yours to be pulled out of a real stuck situation? I can’t imagine those things taking the weight of the vehicle and then some.



[BigSwede]

Have you used yours to be pulled out of a real stuck situation? I can’t imagine those things taking the weight of the vehicle and then some.

Why not? They are sturdily built and bolted directly to the frame. I've been wheeling for 20+ years and they look fine to me.

My previous FJ Cruiser had the same points, and there were a few failures reported but were attributed to rusted welds, but they served me well in the 7 years I had the FJ.



[Bang Bang]

Why not? They are sturdily built and bolted directly to the frame. I've been wheeling for 20+ years and they look fine to me.

My previous FJ Cruiser had the same points, and there were a few failures reported but were attributed to rusted welds, but they served me well in the 7 years I had the FJ.

Because they are only listed as tie down points for transport. They just don’t look beefy enough to me to pull my truck out of a really stuck spot.



[r2m]

Because they are only listed as tie down points for transport. They just don’t look beefy enough to me to pull my truck out of a really stuck spot.

Well, there may be only one way to find out! Ha-ha!
Anyone volunteer to to get real stuck and give them a tug?



[jmanscotch]

I have a pair of Trail Tailors no longer available GX460 front recovery points, raw metal with rounded holes for soft shackles, that need a new home now that I’ve sold the GX, $75 shipped, no hardware, just metal mounts.



[re_guderian]

I have a pair of Trail Tailors no longer available GX460 front recovery points, raw metal with rounded holes for soft shackles, that need a new home now that I’ve sold the GX, $75 shipped, no hardware, just metal mounts.

View attachment 2968248

View attachment 2968249

View attachment 2968250

Man, where were you with those cam tab gussets a month ago when I needed some???

Do you miss the GX?



[jmanscotch]

Man, where were you with those cam tab gussets a month ago when I needed some???

Do you miss the GX?

Been sitting on them for a year…my bad. Never did install them when I replaced my LCAs as my welder ran out of gas on a Sunday, ended up going to a guy that was gonna copy the design and reproduce them I guess.

Do I miss the GX? Nah, bought it in January 2020 and just sold it last month for $7k more than I paid for it and got into a 2021 Tacoma TRD OR DCLB…needed a truck again and while the GX was nice, I had a bit of a jaded ownership with the coolant valley leak and ~$5k of parts for other repairs. With a newborn at home, I’m happy to be in a rig with a factory warranty so I have my weekends back to be a dad and not a DIY mechanic.

The Taco is clearly not as refined, but gets 3 times the gas mileage, rides better than my lifted GX did, fits our family of 3 just the same and has the great utility of a bed.
