Okay, I used the search option, but could not find anything on this. Does anyone know how easy (or difficult) it would be to convert a U.S. spec 80 to a manual transmission? What manual transmissions are best suited for this swap?
Converting a U.S. Spec 80 to Manual Transmission
- Thread starter suzuguru
- Start date
This site may earn a commission from merchant affiliate
links, including eBay, Amazon, Skimlinks, and others.
5 second find. When you search, go to google an search: 5 speed manual transmission fzj80 ih8mud
forum.ih8mud.com
How difficult? How deep are your pockets?
80 Series H151F 5 Speed Manual Transmission Swap - Includes RHD HDJ81 & LHD FZJ80
I figured it's time for me to contribute to the forum. I wanted to create a thread of my experiences with this swap in order to inform other guys that might be interested in this. The goal of this thread is to give MAXIMUM information and part #s to the other 2 1/2 :banana: mechanics...
forum.ih8mud.com
How difficult? How deep are your pockets?
- Thread starter
- #4
I guess I suck at searching, because I searched on here and also did a google search. Next time, I'll try the google search in your format.5 second find. When you search, go to google an search: 5 speed manual transmission fzj80 ih8mud
80 Series H151F 5 Speed Manual Transmission Swap - Includes RHD HDJ81 & LHD FZJ80
I figured it's time for me to contribute to the forum. I wanted to create a thread of my experiences with this swap in order to inform other guys that might be interested in this. The goal of this thread is to give MAXIMUM information and part #s to the other 2 1/2 :banana: mechanics...
How difficult? How deep are your pockets?
I don't mind the money so much, but the process looks like a PITA.
Last edited:
- Thread starter
- #5
Thanks for the advice, but I would definitely rather have the 1FZFE.
For the trouble, maybe a completely different engine/trans would be smart.
- Thread starter
- #7
Well, as far as gas engines go, the 1FZFE is a great engine. I just don't like automatics.
Fj80oregon
GOLD Star
Maybe look out for a stock manual import. Then swap over your goodies and sell your rig.
- Thread starter
- #9
Good idea, but I don't even have one yet. I'm thinking about getting one just for that purpose.
Actually, I've wanted an 80 for a long time, but having an auto option only, has always stopped me.
It's about 8-10k to get an h151f swap done in an 80, and If you can't weld your self you'll need to pay a shop to fix your trans/tcase mount issue. Drilling the firewall for the master cylinder requires tool and knowledge and there is a small amount of wiring that needs to be re done, lastly you'll need to sort out your shifter console and trim should you choose to put it back. Add to that the cost of an 80 and now your what 20-25k into this project assuming you do all the work yourself and only have parts costs? I swapped mine and it's not crazy difficult if you have some knowledge.
- Thread starter
- #11
I don’t have specific Land Cruiser knowledge, but I’m pretty mechanically minded. I do industrial maintenance for a living. Welding and fabrication isn’t a problem for me. My main concerns are knowing where exactly to put this and that. I’m not real keen on automotive wiring, though.
Then your most difficult part will be getting all the parts together, none of these items came to the usa so you'll have to get everything imported. It can be done, it's been done plenty of times and documented fairly well on here. The parts are no different than any other manual trans truck and the technical service manuals are all posted on here as well in the resources section.
- Thread starter
- #14
When the time comes, I'm sure there are some members here who can help me source needed parts also.
Will and H151 Bolt up to a 1FZFE, or do I need to use an adapter plate?
Edit: After reading through the entire thread that OGBeno mentioned previously, I *think* the transmission would mate up to the 1FZFE, but it seems there might be some trouble with the transmission input shaft length due to differences in the back of the engines??
Will and H151 Bolt up to a 1FZFE, or do I need to use an adapter plate?
Edit: After reading through the entire thread that OGBeno mentioned previously, I *think* the transmission would mate up to the 1FZFE, but it seems there might be some trouble with the transmission input shaft length due to differences in the back of the engines??
Last edited:
The h151s were offered behind several engines including the 1fz, but yes the h151 can 100% bolt onto a 1fz using all oem toyota parts
- Thread starter
- #16
Awesome! Good to know. Thanks!
Sooo, you don't even have an 80 yet? Hmmmm, As was mentioned before, get one that was manual, factory built. Since you're in still the looking mode, make the manual tranny a must on your list of features for your prize 80. The energy spent IMHO, would be much more efficient and realistic, unless you have masochistic tendencies (not in the sexual sense, but in the general sense).
Truly, I hear you, though. I think the biggest, if not the only regret of my '94, is the auto tranny. And it works flawlessly - for an auto - actually the best auto of any auto truck or SUV I've owned. I prefer a manual, I guess because that's what I started with and enjoy their performance compared with autos. But, as you know, U.S. spec 80's were exclusively autos and after driving my other manual rigs and jump into the 80, start driving it, getting back into the 'auto mode', I'm fine for a while until coming up to a light or stop sign and find myself grabbing the shifter while trying to mash the dead pedal though the firewall
. Ya just have to keep that sense of humor - it's critical
. One day, I'd like to drive a manual 1FZ 80, though!
Last edited:
- Thread starter
- #18
Sooo, you don't even have an 80 yet? Hmmmm, As was mentioned before, get one that was manual, factory built. Since you're in still the looking mode, make the manual tranny a must on your list of features for your prize 80. The energy spent IMHO, would be much for efficient and realistic, unless you have masochistic tendencies (not in the sexual sense, but in the general sense).
Truly, I hear you, though. I think the biggest, if not the only regret of my '94, is the auto tranny. And it works flawlessly - for an auto - actually the best auto of any auto truck or SUV I've owned. I prefer a manual, I guess because that's what I started with and enjoy their performance compared with autos. But, as you know, U.S. spec 80's were exclusively autos and after driving my other manual rigs and jump into the 80, start driving it, getting back into the 'auto mode', I'm fine for a while until coming up to a light or stop sign and find myself grabbing the shifter while trying to mash the dead pedal though the firewall
If I could find one for a price that’s remotely comparable to what I would end up spending on the whole shooting match, I’d be happy to go that route. I don’t doubt for a minute that those autos in the US spec 80’s are great. I just really, really prefer to drive manuals.
If I had a dollar for everytime I've slammed on the brakes with my left foot....Sooo, you don't even have an 80 yet? Hmmmm, As was mentioned before, get one that was manual, factory built. Since you're in still the looking mode, make the manual tranny a must on your list of features for your prize 80. The energy spent IMHO, would be much for efficient and realistic, unless you have masochistic tendencies (not in the sexual sense, but in the general sense).
Truly, I hear you, though. I think the biggest, if not the only regret of my '94, is the auto tranny. And it works flawlessly - for an auto - actually the best auto of any auto truck or SUV I've owned. I prefer a manual, I guess because that's what I started with and enjoy their performance compared with autos. But, as you know, U.S. spec 80's were exclusively autos and after driving my other manual rigs and jump into the 80, start driving it, getting back into the 'auto mode', I'm fine for a while until coming up to a light or stop sign and find myself grabbing the shifter while trying to mash the dead pedal though the firewall
I've seen people who use their left foot for the break pedal frequently, if not exclusively. I can do it, while driving an auto, but not very well. I'm thinking it's my manual instincts that make it difficult to do. I have the same problem on 2 wheels using my foot to shift, hand clutch, hand thottle and separate front and rear brake levers. Yeah, I can do it, but not very well!
