Builds Build Thomas FJ48 (2 Viewers)

[Farmer Thomas]

This build is awesome. Can you tell give me some more details about the mirrors and bonnet hooks your using?
Like how the mirrors mount to the door hinges.

The mirrors are from icon:

ICON FJ Side View Mirrors

Designed by ICON, and CNC'ed in aluminum. Super steady views, highest quality construction. Compatible with FJ40, FJ45, Land Cruisers and feel free to fit them on anything you like. For FJ40 and FJ45, choose between door hinge mount and door panel mount style. Laser cut quality UV stable...

shop.icon4x4.com

They were pricy but I could not find anything a liked better. Extremely happy with there quality and hardware provided. I also bought there centre console. Will update with a picture once installed.

The hood hooks I believe are Rugged Ridge. When I did all my metal work on the hood, I filled the original holes and reinforced the hook area with a metal plate. Still need to find something for the hood to windshield hooks. Trying to find a black set but everyone seems to be sold out.



[Farmer Thomas]

I finally got a chance to fire the Cummins as well. It sounds pretty badass. Most of my gauges are hooked up and wired to the Holley digital dash but still have some cleanup of the wiring under the hood.



[frankenyota]

Thanks for the info, those bonnet latches look solid. I was looking at the mirrors from a land rover defender which are very similar to the icon ones but they mount to the door panel. Only picture l can find on a FJ40



[Paul]

95% of the wiring and plumbing is done and hope to fire the engine this week. Just waiting on a few parts. Will starting working on fitting everything this week as well. Will be interesting on how it all comes together after the linexView attachment 2993290View attachment 2993291View attachment 2993292

What tail light are you running? I’m looking for a set that requires minimal hole saw size.



[Farmer Thomas]

What tail light are you running? I’m looking for a set that requires minimal hole saw size.

Rear taillights are made by JW Speaker. The holes were minimal 4 corners for the hardware and one small hole to pull wires through.



[Paul]

Rear taillights are made by JW Speaker. The holes were minimal 4 corners for the hardware and one small hole to pull wires through.View attachment 3256743View attachment 3256728

Perfect. Exactly what I’m looking for. Thanks.



[Mike Shull]

Oops! I posted to the wrong thread. Keep up the excellent work. I deleted my pictures and I’ll repost in my thread.



[Farmer Thomas]

Just got the roof back from linex! Turned out great. Windows and seals next.



[peesalot]

Your attention to detail shows, really nicely put together.



[Mike Shull]

Your attention to detail shows, really nicely put together.

I echo this. It could pass as an Icon



[Farmer Thomas]

Your attention to detail shows, really nicely put together.

Thank for the words of encouragement. Spent hrs reading through other builds to get good ideas and advice. Great community!!



[peesalot]

Those hood latches are nice but may hold too rigid as the oem ones have alot of spring and when crossed up it moves, maybe not so much on your chassis.
Whats the red ecm on firewall ? I see the main engine one so curious ? and the black box in front corner ?



[peesalot]

Did you buy the seats or have them made ?



[Farmer Thomas]

Thank for the words of encouragement. Spent hrs reading through other builds to get good ideas and advice. Great community!!

Those hood latches are nice but may hold too rigid as the oem ones have alot of spring and when crossed up it moves, maybe not so much on your chassis.
Whats the red ecm on firewall ? I see the main engine one so curious ? and the black box in front corner ?

Great point on the hood latches. Will have to keep an eye on them when there is flex.

The red ECM is the 4l80e transmission controller (Compushift) to the cummins.

4L80E transmission controller

Control your 4L60E, 4L80E, 4R70W, E4OD or 4R100 transmission. Bluetooth/App enabled, US Made, Stunning Billet Waterproof Case. Check it out!

hgmelectronics.com

Black box is a Garmin power switch. It controls all the auxiliary lights from the Garmin screen.

Garmin PowerSwitch™ | Compact Digital Switch Box

Garmin PowerSwitch is the digital switch box that offers control of your off-road vehicle’s 12-volt accessories from a compatible Garmin navigator or smartphone.

www.garmin.com



[Farmer Thomas]

Did you buy the seats or have them made ?

Seats are made by PRP. Great to deal with and was able to custom them right on there website.

PRP OFF-ROAD SEATS AND GEAR

PRP is the leading manufacturer of customizable seats and gear for upgrading your UTV, Jeep, or truck. Don't settle for less!

www.prpseats.com



[peesalot]

How many things will that garmin handle and I suppose it switches relays ?



[Farmer Thomas]

How many things will that garmin handle and I suppose it switches relays ?

The garmin switch does 6 different accessories. Works over Bluetooth to remotely activate if needed



[Chris Carrera]

Flamming river.

@Farmer Thomas - can you share the length you ordered?



[Farmer Thomas]

Have not had much time to work on over the summer but got the windows in and a few electrical bugs worked out. Waiting on the new axels from dynatrac for my winter project then hope to finally have this thing running in the spring!

Trying to track down some hardware for the rear kick-out windows if anyone has some ideas where to look? Also if anyone has a suggestion on what rubber gasket seal to use between windshield and cowl on the Aqualu bodies let me know. Original style does not work



[Mike Shull]

View attachment 3472992
View attachment 3472993


Have not had much time to work on over the summer but got the windows in and a few electrical bugs worked out. Waiting on the new axels from dynatrac for my winter project then hope to finally have this thing running in the spring!

Trying to track down some hardware for the rear kick-out windows if anyone has some ideas where to look? Also if anyone has a suggestion on what rubber gasket seal to use between windshield and cowl on the Aqualu bodies let me know. Original style does not work

Those windows look pretty sweet!
