This will be my second, and improved drawer system.


But this time I want to do try to do something really clean, and innovative. I want to make it as light as possible, while keeping the highest structural integrity and strength possible.
I plan to achieve this by using a small steal sub frame and 9ply 1/2 inch plywood, and a new type of tie down that will be light and vercitile.
I will do my best to use only the highest quality hardware, and materials.

Let the build begin! I will post pictures tomorrow when I start on the metal sub frame.

Joined
Jan 27, 2008
Messages
1,002
Location
Socal/ I.E.
Today I was able to finish my sub frame.






I just have to prime, then I should be installing tomorrow. After I get the frame installed I will start cutting the wood pisces.


alia176

SILVER Star
Joined
Aug 21, 2003
Messages
12,794
Location
Tijeras, NM
is that 1/2" plywood or 12mm mill finished Birch plywood? I've good luck with the 12mm Birch from Home Depot.

Looking forward to your finished product!

Joined
Jan 27, 2008
Messages
1,002
Location
Socal/ I.E.
The sheet of plywood that you see in that photo is 1/2" raw birch. The sheet I am going to use for this project is 9ply 1/2" prefinished maple.

Joined
Jan 27, 2008
Messages
1,002
Location
Socal/ I.E.
Today I was able to paint, and install the sub frame. Here are some pics.





This was only a dry fit. I will take it out and start assembling tomorrow.

Thanks.

Last edited:
Joined
Jan 27, 2008
Messages
1,002
Location
Socal/ I.E.
I was rushed to get of the house yesterday, but before I left I was able to finish the drawers for this project.

It will be Tuesday before I am able to work on this again.
Thanks

Joined
Aug 20, 2004
Messages
1,930
Location
A balanced city
Charles its Tuseday night got any new pics for us??? My storage that I got from you is just the same way I got it from you so just giving you hard time...:beer:

Joined
Dec 10, 2008
Messages
57
Location
Bozeman MT
That's nice, I cant wait to build mine, I like ur frame design its different and similar to what I am thinking of doing

Caleb


619TOY

SILVER Star
Joined
Jun 27, 2006
Messages
2,025
Location
San Diego
Looking good. Using the prefinished wood really does make things easier. I would have used prefinished if I weren't planning on dousing it all with Line-X and black paint:D

One thing I did notice that you were missing though, is the Doberman to keep you company while you work;p
1-17-07 004.jpg

Joined
Jan 27, 2008
Messages
1,002
Location
Socal/ I.E.
Looking good. Using the prefinished wood really does make things easier. I would have used prefinished if I weren't planning on dousing it all with Line-X and black paint:D

One thing I did notice that you were missing though, is the Doberman to keep you company while you work;p

Steve, I had a hard time deciding to do wood finish Vs. line-X, I went with wood this time. I figure that I could always Line-X latter. As far Dobermans go. Scotty is not good to play in the front yard (if a bike goes by.... It will not get to far:eek:)

Thanks to all, Merry Christmas.

Joined
Jun 30, 2003
Messages
2,081
why line-x it? it will rough and bumpy and uncomfortable. it will wear fabric that is placed on it and trap dust and dirt. it will cut your skin if you scrape against it and it will hurt to kneel on if you are in shorts or whatever. i know you dont me from Adam but why not try smooth Durabak? Cote-L Distribution Company

Joined
Jan 27, 2008
Messages
1,002
Location
Socal/ I.E.
I am planing to do the entire outside of my rig with durabak. But my last drawer was Line-X and I liked it alot, that being said I can see where you are coming from. it does not matter anyway becouse I am planing to leave it wood.
