Chet's 1974 FJ55 Build

This site may earn a commission from merchant affiliate
links, including eBay, Amazon, Skimlinks, and others.

Picked up a set of Ford F-250 seats with built in seat belts. I have a question for anybody that used new seats. Do you need to hook some sort of power source to the seat belt to make it lock when braking? There is a deal attached to the seat by the seatbelt and it must hook into the ford's computer. I will need to come up with some sort of frame or bend the tabs so they will mount up ok. Very comfy seats :)


Most locking seat belts use a inertia switch inside of them to lock when they're at an angle or pulled on hard. It could be hooked into the body computer to lock when the air bags deploy or just to tell the computer the status of the seat belts.

I've been slowly plinking along on the pig. I finally finished ripping up the black plastic flooring that was cemented to the floor as well as wire wheeling and sandblasting any and all rust. I treated the floor with a rust prohibitor until I could spray in the Gator Guard II Bedliner. I used the Por-15 putty to fill all of the tiny sheetmetal screws that were used to secure the nasty shag carpet down. That stuff is pretty cool, hardens really well. I also made some supports for the long range gas tank and got them attched before doing the bedliner.
I sprayed in the bedliner using the undercarriage gun and it came out pretty good. Only issue was the temp here was lower than ideal and the stuff was going on thicker than I planned. I ended up using 3 of the .45 gal kits and still need another one. That stuff stinks something awful when your spraying it. Make sure and wear a respirator, I didn't at first and was seeing pink elephants for a while ;)

Pictures.












PabloCruise - Thanks, I still need to go back over a few areas. That's the bad part about spraying it and working my way back thru the tailgate. When I looked thru the passenger door I saw all the areas I missed. All and all I'm happy with it. It's the Gator Guard II White and it is gooey sticky stuff. You can see where I accidently sprayed the passenger door and glovebox area. That's going to be fun to clean :bang:
I need to do the back of the rear bench and then it's off to be re-upholstered. I'm just going with black vinyl to match the front seats I picked up. I'm getting anxious to drive this thing while it's still nice here. A/C is really something I need to start looking into.. Just so much $$$

Thanks guys, the silver is Rustoleum Hammered. I used it on the front and back bumpers, grill, side vents, air cleaner, battery tray and the rear seat mounts as well as the rear seat trim. I bought it from Home Depot around $6.50 a can.

Here's a link. RustOleum.com

Rock Hill FJ55 - Thanks, it's the White Gator Guard II Spray-In Bedliner. I used a cheap Undercoating gun to spray it on. I bought the .45 hal kits and ended up using 4 of them so Your better off buying the gallon kits they have. I'd also recommend thinning it a bit. Mine went on really thick. It goes on better when it's at least 70+ degrees outside. Make sure and wear a respirator...I forgot at first and was high as a kite for a little bit. ;)

Eastwood Co. - White Gator Guard II Truck Bed liner

1979fj40 said:
wasnt really a 55 fan , but now I,m starting to want a piggy to build. Wish I could find one close. Nice truck!
Click to expand...

Thanks! It has been a learning experience to say the least. The 55 series is really a pain to find parts for compared to just about any of the FJ's around. I know it has to do with how many were sold but it still amazes me what you can get for the 40 & 45 series.

I hope to get the brackets made for the front seats this weekend, Inkpot on mud here has agreed to weld them up for me. I'm having all of the fluids flushed and changed tomorrow. I know I should do it but... I don't want to. :crybaby: Messy, Messy. To change the front & rear diffs, transfer case, transmission and oil change they are charging $203.00 Seemed reasonable to me.

Still debating on doing the napa hinge repair or buying the rebuilt from SOR. Anybody here use the SOR ones? I think just the front's need to be replaced. I'm also trying to figure out the best insulation for the roof. I want to get the headliner in so I can get the rear cargo glass in and the windshield replaced. Second Skin is here in the valley so I might take a trip over and see what they recommend.

I also have a major case of "The Cruiser Lean" not sure if it's the shocks, leaf springs or body mounts. The rear looks like it's sagging a bit compared to the front. What is the most common cause and fix?

I know I take a lot of pictures but :flipoff2: I like them.












Lookin' great Chet. Really like the Gator Liner and your use of the "hammered finish" on different areas of your pig. Those are some shiny white wheels. Did I miss where you got those/or cleaned them up? Too many pictures? I don't think so! Thanks for sharing the many photos!!!!!Dave

Thanks Dave, the wheels are new old stock steel from toyota and I had them powdercoated white. If they would of come in the original grey I would of left them but they were black. Yeah I'm a fan of the silver hammered paint. We'll see how long it holds up. I just finished the back bumper the other day but haven't taken any photos recently.

Well not much done lately, put new battery cables on. The old ones came apart in my hand when I took them off. Had all the fluids changed and brought it over to inkpots to see about welding up some brackets for my front seats. Still have to figure that one out.

I wanted to take the front turn signals off and sand them down and paint them but ended up destroying one of them... 35 year old plastic is a little brittle, add a rusted out bolt and you got hour plus mess :( My passenger brake light isn't working now. I'm hoping it's because the turn signal is gone in the front? I replaced the brake switch (broken in 2) but it didn't seem to help. I have a new set of the 75+ FJ40, 55 turn signals but need the correct foot for them. Anybody know who sells them or the correct front turn signals?

On a good note my daughter was born on Friday morning and we finally get to go home tomorrow.

Here's a pic. of Camille 9lbs 11 oz
