Pro-Mod #247 Build-Up

Discussion in 'HardCore Corner' started by Marko, Feb 26, 2007.

  1. Marko

    Marko

    Messages:
    94
    Likes Received:
    0
    Joined:
    Apr 5, 2005
    Location:
    Columbia, MO
    I love hitting the hard trails and recently have found interest the competitions it adds a bit more. We love traveling and the interaction of the fans, competitors, and different type of obsticles based on different locations and bulding rigs with competitive edge different from the "norm" and push the status quo. It's the challenge I love.

    Here's some specs:

    The Chassis is one of my designs modified to fit the class rules.

    The Chassis is a M-Chassis/ Type C.

    Tires: 37 PitBull Rockers
    Winch: Ramsey Tri-X 6000
    Axles: D60s, Detroits, 35 Front /40 spline Rear
    Engine: V6 3.4L
    Tranny: 3 spd
    Shocks: 14" Bilsteins C/O
    Hiems: QSC, Inc. 5/8 x 3/4
    Skins: FJ 40


    Motor Mounts:
    [​IMG][​IMG]
    [​IMG]

    Front truss/Link Mounts:
    [​IMG][​IMG]

    [​IMG][​IMG]

    Seat Mounts:

    [​IMG][​IMG]

    More Later.......

    Thanks for looking.

    -John

    Last edited: Feb 27, 2007
  2. Hank

    Hank SILVER Star

    Messages:
    1,420
    Albums:
    1
    Likes Received:
    8
    Joined:
    Feb 5, 2003
    Location:
    Oshkosh, WI
    More pics? Do you have an overall sketch, drawing or print you are working from?

  3. Marko

    Marko

    Messages:
    94
    Likes Received:
    0
    Joined:
    Apr 5, 2005
    Location:
    Columbia, MO
    Yep, We have a print, sketch, drawing, specs, and a chassis.

  4. Marko

    Marko

    Messages:
    94
    Likes Received:
    0
    Joined:
    Apr 5, 2005
    Location:
    Columbia, MO
    Little back ground on the M-Chassis we're working from. I originally designed it for as a hard trail buggy streamlined down than most trail buggies and possiblity to cross over to Rock Racing. It's also not really built to look like a FJ or CJ just making the form fit the intended function. However, I think it does have nice lines. You all can tell me what the lines really look like. I may be a bit bias as for it's looks

    The Type C is built solely for comps and severe/extreme trails, but it lacks comfort in the area of space and is pretty much truely purpose built. You'll find no gauges, no radio, two seats, brakes,steering wheel, throttle, shifter, and 4 switches on the dash.

    Here's an earlier chassis:

    [​IMG]

    Sorry for the dark photo.

  5. LC_Hamma

    LC_Hamma The Anti-Leafer

    Messages:
    2,661
    Likes Received:
    10
    Joined:
    Nov 11, 2002
    Location:
    Dallas, Georgia
    Top notch fabbin there! Can you order 40 spline Detroits or is there just some special machinework to rebroach the sde gears? I'm guessing 40 spline inners only? Where'd you get the inner diff seal? Why'd you choose the low pinion housings? You running deeper than 5.38's?

  6. Marko

    Marko

    Messages:
    94
    Likes Received:
    0
    Joined:
    Apr 5, 2005
    Location:
    Columbia, MO
    The rears 40 spline yep stock detroit, the front I left 35 spline for simplicity reasons. Sorry, if I mislead. I had the LP frt and rear laying in the corner of the shop figured I'd go ahead and put it to use.

    This rig has been built with fairly low budget for what it is competing against, but that just adds to the challenge.

  7. Marko

    Marko

    Messages:
    94
    Likes Received:
    0
    Joined:
    Apr 5, 2005
    Location:
    Columbia, MO
    Some pics of the Cockpit:

    [​IMG]

    [​IMG]

  8. camcruiser13

    camcruiser13

    Messages:
    6,971
    Media:
    3
    Albums:
    1
    Likes Received:
    21
    Joined:
    Jun 22, 2004
    Location:
    sittin on the couch in UT
    wow, nice looking welds, get a shot in the light i want more details on that rig


    keep it up

  9. Marko

    Marko

    Messages:
    94
    Likes Received:
    0
    Joined:
    Apr 5, 2005
    Location:
    Columbia, MO
    The shot in the dark isn't the same rig. That one is the standard version which much more trail/passenger comfort built. That is a touch longer wheelbase around 105-9" and several different drive trains fit well it those. I just wanted to give a since of the chassis' basic design I've adapted for a particular purpose Comps.

    Full pics of the chassis are coming.................

  10. camcruiser13

    camcruiser13

    Messages:
    6,971
    Media:
    3
    Albums:
    1
    Likes Received:
    21
    Joined:
    Jun 22, 2004
    Location:
    sittin on the couch in UT
  11. woody

    woody unhelpful spotter Staff Member Admin

    Messages:
    10,634
    Media:
    317
    Albums:
    7
    Likes Received:
    1,937
    Joined:
    Jan 15, 2002
    Location:
    Toquerville UT
    great work....more more more ;)

  12. Marko

    Marko

    Messages:
    94
    Likes Received:
    0
    Joined:
    Apr 5, 2005
    Location:
    Columbia, MO
    Got some goodies in last week.

    Like to thank Pit Bull Tires and Drive Train Specialist out of Detroit, MI.

    We're a new team in the Comp circuits but that were the "new-ness"
    ends. We're very grateful for any sponsorship recieved from great companies. It makes a huge positive impact for our team.

    Now some pics........................

    [​IMG]

    [​IMG]

    Got the ROCKERS mounted up on the wheels for the 15 Hour NightMARE Run at Flat Nasty this weekend. Time to breakem' in, I got another set of out lock rings painted and ready to go on for the debute at WE Rock Comp. on April 14th. These are just for testing.

    Pay no attention to the vehicle that they're attached to. Yes it was the one I was in at the TCLA/TAC event last Oct.

    [​IMG]

  13. Nightcrawler4x4

    Nightcrawler4x4

    Messages:
    30
    Likes Received:
    0
    Joined:
    Aug 21, 2004
    Location:
    St. Louis, MO
    So how did the Pit Bull tires hook up for ya? My new 42" Iroks were doing a hell of a good job, they went ever where the 44s and 49s did. Can't wait to see ya sportin the FJ 40 look, guess I'll have to get going on mine as well.

  14. Marko

    Marko

    Messages:
    94
    Likes Received:
    0
    Joined:
    Apr 5, 2005
    Location:
    Columbia, MO
    The Pit Bull Rockers hooked great. On trail 6a started off with nice momentum and got a bit sideways at the crux ledge, did a quick front dig, corrected it, and shot right up. They're breaking in awesome and got quite a bit more sticky as the night progressed. They stuck like glue by the time we got to the waterfalls.

    The 40 skins are going to be sweet and simple. Got a nice color scheme layed out.

    You need to get rockin on that one of yours.

    Last edited: Mar 13, 2007
  15. Marko

    Marko

    Messages:
    94
    Likes Received:
    0
    Joined:
    Apr 5, 2005
    Location:
    Columbia, MO
    More pics.........

    [​IMG]

    Guess were these went.









    They're in there some were........

    [​IMG]

    Sneak peak at the chassis's rear suspension.............

    [​IMG]

  16. Marko

    Marko

    Messages:
    94
    Likes Received:
    0
    Joined:
    Apr 5, 2005
    Location:
    Columbia, MO
    More of the rear.................
    [​IMG]



    [​IMG]

    [​IMG][​IMG]

  17. LC_Hamma

    LC_Hamma The Anti-Leafer

    Messages:
    2,661
    Likes Received:
    10
    Joined:
    Nov 11, 2002
    Location:
    Dallas, Georgia
    :cool: Female Dobie. I got one of those too - 13 yrs. old. She's my :princess:
    She looks about 1 yr. old & very healthy.

    I like the extensive use of the dimple die panels & the way you used tube between them :smokin: Looks like the links are all set. What's the curved panel located on top of the housing for? Extra bracing? That looks like a HD Dana 60 with the double flange around the rear of the housing.

    Last edited: Mar 18, 2007
  18. Marko

    Marko

    Messages:
    94
    Likes Received:
    0
    Joined:
    Apr 5, 2005
    Location:
    Columbia, MO
    That's "Black Dogg", he just over a year old. It's a male he a bit smaller than normal right at around 65lbs. Guess he grew up to be the runt. He's healthy just small. He's awesome, friendly, loving, and handy to have around when working alone late nights at shop. This is the third dobie we had I love 'em great family dogs. One female that a carbon copy of this one but with the ultra long cut ears and another male that reminds you more of a sharp tooth pony. That one is my sister's and is spoiled rotten..

    It's a standard D60, I believe it came from a 3/4 ton ford????????
    The part that looks like double flange is part of the truss/tiedown in the pic it looks just like a HD version. It's a laminate similiar to the front. Nice eye.

    The curved panel is my sick way of placing a 2 tabs to suck down the rear and mount a limiting strap. Notice the milled slot on the top. that's where the tab will live. It does proved some extra bracing.

    The dimples add a extra touch. I made these a 1" and 1.75." The work nice with the work I do. The limits are .125 mild / .100 Cromo on the 1" and .188 mild/ .134 Cromo on the 1.75.

    I glad to say that that the last of the major fabrication to be done on this buggy until I get to the skins. Now to mounting the winches, coolers, computers, batteries, linkages, shifters, steering, etc......................

    [​IMG][​IMG]

    Here he's up close for his mug shot and him with my sister's pony.

  19. brayn

    brayn

    Messages:
    79
    Likes Received:
    0
    Joined:
    Dec 31, 2005
    Location:
    S26 34.763 E18 08.057
    Very Cooool!!
    Do you fab the plates with the holes yourself,or do you get it stamped already!
    Keep posting!!

  20. LC_Hamma

    LC_Hamma The Anti-Leafer

    Messages:
    2,661
    Likes Received:
    10
    Joined:
    Nov 11, 2002
    Location:
    Dallas, Georgia
    That's "Black Dogg", he just over a year old. It's a male he a bit smaller than normal right at around 65lbs. Guess he grew up to be the runt.

    :doh: Wrong on both counts. I thought I could pick 'em out. His darker tan color threw me as the 3 males I've owned were lighter. And, the females are *generally known to be dark tan.

    Do you fab the plates with the holes yourself,or do you get it stamped already!
    Keep posting!!

    You can buy dimple dies from various steel fab vendors. They are made to work with your press.

    Are you welding most of the compound brackets off the rig on a flat surface? I ask that cuz I'm curious to know if you're welding uphill or able to lay things flat w/ the mig? I'll use dimple dies on my next buildup. Looks great man! :cool:

    Thought I'd throw in an old pic of my beloved one's: Sampson (R.I.P.) & Delilah:
