New Aux 12v Outlets (USB/12v/Voltmeter)

This site may earn a commission from merchant affiliate
links, including eBay, Amazon, Skimlinks, and others.

FloridaFJ80

Roaming Land Cruiser Heaven
Joined
Sep 11, 2005
Threads
185
Messages
2,997
Location
Ashburn, Va
Website
www.landcruiserheaven.com
I wanted to offer these 12v sockets to the MUD community, great for adding ports to your existing dual battery setup. These are equivalent to the Blue Sea sockets in terms of quality.

Minimum order: 2 units

Please add $10 for shipping and Paypal fees to total price.

Specs:
- Motorcycle, ATV, Boat, RV, USB Weatherproof Power Socket - USB Charger (optional SAE to USB)
- Direct connect to 12 VDC system (Input voltage is DC 12V +/-4)
- Powers down to USB power requirements (DC 5V +/-0.25 and 2.1A max)
- Heavy Duty All Weather Design with Zippo Cap Design
- Easy to open and use
- Water Resistant, not water immersible
- Add on a SAE or Powerlet plug. SAE to USB or Powerlet to USB!

Dual USB Socket - Flush Mount $16.99





Voltmeter Socket - Flush Mount $16.99



Dual USB Socket with Voltmeter - Flush Mount $25.99




12v Power & Dual USB Socket - Flush Mount $25.99





Dual USB Socket - External Mount $16.99




12v Power & Dual USB Socket - External Mount $28.99




Dual USB Socket with Voltmeter - External Mount $28.99





Last edited:
Here is an install from a fellow mudder Bear Lake Cruiser.

power1-jpg.898819

power2-jpg.898820


power3-jpg.898821

Toyota USB Power Socket $19.50

This socket allows you to charge any device including digital cameras, PDAs, mobile phones and USB accessories. This socket fits on all late model Toyota's SUV’s and some cars, it will give you the charging convenience no matter where you travel. With short circuit protection, the Toyota USB Power Socket is the ideal solution for those who are always on the go. It never overheats and has a dual socket so you can charge two devices at one time. Make keeping your device ready for use simple by using this Socket. It will ensure that you stay connected when you need to the most.

The product is manufactured to fit in the OEM space available in your car or truck, simple to install

• Dual USB ports, can charge two different devices simultaneously
• Color: black
• Material: ABS + Electronic components
• Input voltage: DC 12V
• Output voltage: DC 5V 2.1A

KIT CONTAINS:
• 1 USB Dual power socket
• 1 Connector with cable for easy installation

FITS THESE VEHICLES:
• Toyota FJ Cruiser 2007-2014
• Toyota Fortuner 2005-2014
• Toyota Hilux 2005-2014
• Toyota Tacoma 2005-2011
• Toyota Tacoma 2012-2014 (Left Side ONLY)
• Toyota Highlander 2001-2007
• Toyota Tundra 2005-2007 (Center Console)
• Toyota 4Runner 2003-2009
• Toyota Prado 120 Series 2003-2009
• Toyota Land Cruiser 100 Series 1998-2007
• Toyota Land Cruiser 75, 76, 78 & 79 series



New Dual USB Rocker Switch 12v outlet

Price: $19.50

• Same size as the Carling and ARB switches - Fits 60/80/100 series
• Dual USB ports, can charge two different devices simultaneously
• Color: Black
• LED Color: Blue
• Material: ABS + Electronic components
• Input voltage: DC 12V – 24V
• Output voltage: DC 5V 3.1A




Last edited:
Is that 2.1A joined across both devices or is that 2.1A each?

Its a total of 2.1a for the outlet. When 1 device is plugged in it will charge at 2.1A. when 2 devices plugged in it will charge each @ 1A.

Yeah, I'm also curious about the Toy USB Socket for an 80. How far off from fitting is it?

I am working on a solution to making them fit into the 80 series dash outlet. Will have some more information when I return from my business trip.

Are there any pics of the external mounts installed? I'm interested in the dual USB + voltmeter external mount but I would like to know where others have put this or something similar that is out of the way yet easy to access.

Angelo send me your email address and i will send you a paypal invoice. Is there any other switch you want.

Are there any pics of the external mounts installed? I'm interested in the dual USB + voltmeter external mount but I would like to know where others have put this or something similar that is out of the way yet easy to access.
You can be the first one.

It should fit slightly loose in an 80. That's how switches that are made for newer models fit anyway. You can give them a few wraps of electrical tape to tighten them up but I prefer a more direct fit solution.

New Dual USB Rocker Switch 12v outlet

Price: $19.50

• Same size as the Carling and ARB switches
• Dual USB ports, can charge two different devices simultaneously
• Color: Black
• LED Color: Blue
• Material: ABS + Electronic components
• Input voltage: DC 12V – 24V
• Output voltage: DC 5V 3.1A




New small USB power supply $19.50



FITS THESE VEHICLES:
• Toyota Tacoma 2012-2014 (Center Console ONLY)
• Toyota Tundra 2007-2014
• Toyota 4Runner 2010-2014
• Toyota Land Cruiser Prado 150 Series 2010-2014
• Toyota Land Cruiser 200 Series 2008-2013
• Toyota Sequoia 2008-2014
• Toyota Corolla 2006-2013
• Toyota Camry 2011-2014

did Doughboy get it to work in the dash of an 80?
which plug did you use? or does it have to have a dedicated hot lead all the way to the fuse panel ?
