What's the best engine? (1 Viewer)

Joined
Jun 11, 2018
Messages
14
Location
Helena,montana
I wanna put a new (different) engine in my 1965 fj40. Toyota preferably, diesel would be nice but with some sort of noise reduction or insulation? At very least something with multi-port fuel injection. If it could match a th350 tranny that would be very sweet!
A complete package ready to run would also be very nice.


3_puppies

SILVER Star
Joined
Dec 2, 2002
Messages
13,998
Location
Helena MT




Got a nice 2UZ with auto and transfer setup in the valley, might be kinda long for a 40 series
I think the only engine that would go to a th350 would be Chevy
I'd be interested in your old setup when you pull it out.
Paul

Joined
Jan 30, 2010
Messages
2,351
Location
SK Canada


you can get a mercedes OM617 to mate to a chevy belhousing. they’re older but are very good reliable engines. i’m currently putting one in. it’s a bunch of work to get the drive line length in the right sport. it’s a bit tight

Last edited:

Indestructible 47

SILVER Star
Joined
Jun 23, 2014
Messages
1,170
Location
Straya

If you are dead set on an auto, choose your trans before the motor. The shortest possible auto is going to be your friend. Still, if you care about cool, a Toyota diesel straight 6 and a manual trans are where it's at.

Joined
Jan 30, 2010
Messages
2,351
Location
SK Canada


not sure there’s a good solution for 4wd with a th350 is there? is there a reason you want to stick with that tranny?

edit: never mind. i found some threads showing it. just seems like a really long drivetrain.

Joined
Jun 11, 2018
Messages
14
Location
Helena,montana
not sure there’s a good solution for 4wd with a th350 is there? is there a reason you want to stick with that tranny?

edit: never mind. i found some threads showing it. just seems like a really long drivetrain.
I was just looking for something that was compatible.

Joined
Jun 11, 2018
Messages
14
Location
Helena,montana
Got a nice 2UZ with auto and transfer setup in the valley, might be kinda long for a 40 series
I think the only engine that would go to a th350 would be Chevy
I'd be interested in your old setup when you pull it out.
Paul
What's transmission do you have with your 2uz?


Lil'John

SILVER Star
Joined
Mar 24, 2006
Messages
3,250
Location
Lost


Why stuck on a Turbo 350?

To me, unless you are going to stay in the same family of engines that was originally in front of that Turbo 350, you are going to waste a LOT of money adapting. Better to sell it off and start from scratch.

For ease, a Chevy 305/350 TBI/TPI is what you are looking for... maybe LT1 except for crappy Optispark. From there, go with LSx engines.


FJ40Dude

SILVER Star
Joined
Dec 24, 2019
Messages
46
Location
Newport Beach, California
I have been thinking about doing a L84 conversion which is a 5.3 with 300+ HP And Torque

Not sure what the best gearbox would be

Looking for Suggestions also Transfer box

Fj40Dude


Lil'John

SILVER Star
Joined
Mar 24, 2006
Messages
3,250
Location
Lost


I have been thinking about doing a L84 conversion which is a 5.3 with 300+ HP And Torque

Not sure what the best gearbox would be

Looking for Suggestions also Transfer box

Fj40Dude
For transmission, go with what came with it. That will be the easiest/least amount of tuning. On the other hand, I like my NV4500 behind my 6.0 LQ4 engine... once I got some issues resolved.

For transfercase, I'd go with an FJ60/62 split case.

I wouldn't trust stock axles behind that much power. All my cruisers with big power have or are getting Dana 60s(three FJ55s and one FJ40)


FJ40Dude

SILVER Star
Joined
Dec 24, 2019
Messages
46
Location
Newport Beach, California
For transmission, go with what came with it. That will be the easiest/least amount of tuning. On the other hand, I like my NV4500 behind my 6.0 LQ4 engine... once I got some issues resolved.

For transfercase, I'd go with an FJ60/62 split case.

I wouldn't trust stock axles behind that much power. All my cruisers with big power have or are getting Dana 60s(three FJ55s and one FJ40)
The L84 comes with a 10 speed Automatic?
