R151F rebuild and upgrades (1 Viewer)

Joined
Sep 12, 2017
Messages
6
Location
New Zealand
So I'm looking at rebuilding the gearbox in my PZJ70. I'm pretty sure it's a R151F (someone correct me if I'm wrong). I'm wondering if there are any upgraded parts that are better than the stock toyota ones that I should install in it.

I've had a look at some marlin crawler parts and short shifter kit but wondering if there are any other things I should do while it's getting rebuilt. Also is there any rebuild kits that are arguably better than other kits?

Also I'm looking at welding or replacing the dual mass flywheel and was wondering what the best solution is for new clutch/fixed flywheel.

I'm in New Zealand if that matters.

Joined
May 21, 2006
Messages
428
Location
Rotoiti, New Zealand
There was at least one Oz gearbox rebuilder offering upgraded R150s, can't remember the details but have a google & you should find them.

Be aware that although they are super common in many Toyotas there are a few variations between the R15* boxes & many parts are not interchangable.

Cheers
Clint

Joined
Aug 4, 2016
Messages
183
Location
Malta
Maybe you'd want to go for a slightly higher 5th gear, 0.79 overdrive instead of the factory 0.84. This results in a reduction of about 200rpm at cruising speeds.


Joined
Sep 23, 2009
Messages
20
There is some good info for slight upgrades, shifter forks and a 5th gear ratio upgrade in this build thread. Guy used his original r151 behind a 1hdft swap.


Probably my favorite build on here.
I also have a friend here in Chch that rebuilt a r151 from a pzj not long ago for someone, had some small problems with parts as I believe some things are different to the hilux boxes.
If you're local at all he would be good to chat too or possibly willing to do the job.

Joined
Sep 12, 2017
Messages
6
Location
New Zealand
There is some good info for slight upgrades, shifter forks and a 5th gear ratio upgrade in this build thread. Guy used his original r151 behind a 1hdft swap.


Probably my favorite build on here.
I also have a friend here in Chch that rebuilt a r151 from a pzj not long ago for someone, had some small problems with parts as I believe some things are different to the hilux boxes.
If you're local at all he would be good to chat too or possibly willing to do the job.

That sounds bloody good, I'm based in dunners but I'll have a chat to him. Got any contact details you can dm me?
