I need a pic of a stock F engine

[CandyPants]

Is there someone out there that has some picturea of a relatively stock F engine in a pig? Some of the "parts" under the hood have been rearranged in mine and it's looking like my stock air cleaner assembly won't fit because of it.

Thanks!



[clemson55]

Oh Heather do we have to teach you how to use the search function at your HAMOM?

https://forum.ih8mud.com/showthread.php?t=19349&highlight=fj55+engine+bay



[Trollhole]

Though I think both of these are 74.

https://forum.ih8mud.com/showthread.php?t=145560



[CandyPants]

Ha Ha!

No, I saw those when I did use the search function, but I couldn't really see the oil filter very well. I need a pic from straight on and somewhat above....like this one, but not of my goofy ass truck:

Note the oil filter sticking up to the right of the engine...right where the air cleaner needs to be.



[CandyPants]

Marshall...there is one buried in that thread I think I can use.

Although that oil filter doesn't seem to be in the same spot as the others Richard posted. Where is that thing supposed to go? Now I just have to figure out how to re-relocate the oil filter.

Thanks to both of you!



[Pighead]

Oil filter goes right between the fuel pump and the dizzy...with a little aluminum mount between it and the block.

Although that oil filter doesn't seem to be in the same spot as the others Richard posted. Where is that thing supposed to go? Now I just have to figure out how to re-relocate the oil filter.



[CandyPants]

So I guess I need to hunt through all this stuff that was in the back of the pig and see if I have the mount. If not, then I guess I am going to need one. Thanks Pighead.



[toddslater]

K9,

The configuration you have in the pic in post #5 is correct....no need to relocate your oil filter.



[Pighead]

Ooops, that's right. You've got a '73...you're oil filter does bolt on to the intake manifold. My bad.

K9,

The configuration you have in the pic in post #5 is correct....no need to relocate your oil filter.



[clemson55]

Heather yours bolts onto the underside of the manifold.

This is what the bracket looks like, I have one but youll have to get an old canister off it and clean it up.
http://www.sor.com/sor/cat026.tam?c...&lpt=1180697232&xax=11859&page.ctx=cat026.tam

This is a very vague idea of where it goes and what hooks to it.
http://www.sor.com/sor/cat026b.tam?xax=15811



[scorcher1967]

I have pics of a 78, from almost any angle, and for the most part, step by step as each part came off. Shoot a PM if you need a specific one/angle, as there are probably 150+ of the engine bay.



[jfz80]

K9--

this would have to qualify as relatively stock, but here is mine (a 72) Granted that would not be the stock intake but you can see the filter below. BTW a blingin plastichrome intake for a 96 eclipse slips onto the carb perfect . let me know if you still need a shot of the filter and mounting bracketry. kinda sad to post this right after your engine bay shot...............



[Trollhole]

Yeah but your alt more than makes up for everything else.



[CandyPants]

K9--

this would have to qualify as relatively stock, but here is mine (a 72) Granted that would not be the stock intake but you can see the filter below. BTW a blingin plastichrome intake for a 96 eclipse slips onto the carb perfect . let me know if you still need a shot of the filter and mounting bracketry. kinda sad to post this right after your engine bay shot...............

I think I figured it out. Thanks for the picture.

Yeah but your alt more than makes up for everything else.

No kidding, that's the reddest alternator I have ever seen! I think I want to paint mine to match!
