FZJ80 Throttle Body Coolant Leak

Joined
Dec 10, 2020
Messages
10
Location
Newport Beach, CA, USA
Hello,

I'm currently rebuilding my throttle body and found a leak on a plugged port. OEM parts are not available. Is this repairable? Everyone I call locally quickly says this needs to be replaced.

Anyone have any ideas? Weld it?

Thanks!

Josh from Orange County CA

Joined
Jan 5, 2017
Messages
4,169
Location
Charlotte, NC & Alexandria, VA
Why don't you pull out the plug and reconnect the coolant line?

Joined
Dec 10, 2007
Messages
9,155
As mentioned above there's a factory plug in that hole that is now leaking.
Appears that the hole was made when the TB water bypass/heat circuit was being machined, then plugged afterwards.

@Josh714

Might consider cleaning around the plug/hole to check for cracks, but more likely the plug is not sealing. You could pull the plug and measure the ID (I get 10mm on a spare TB), find and replace with a generic aluminum plug using a thread sealer or epoxy.

Looking closely at the plug it may be solid aluminum maybe with a step?? If it is you might be able to drill/tap a hole in the center, pull it, then look for a replacement??


For others, compare this photo of an original/spare TB to the OP's photo
(I enlarged it for detail)

Op's TB with leaking plug:

FZJ80 Throttle Body leaking hole plug cropped 2.png



Spare TB showing the plug (not leaking)
(double click to magnify)

FZJ80 Throttle Body hole plug.jpg

Last edited:

cruiserdan

SupportingVendor Emeritus
Moderator
Joined
Mar 27, 2003
Messages
25,569
Location
Land Cruiser Heritage Museum broom closet
Plan B would be to bypass the coolant heating. I considered that for my supercharged application to reduce heat soak in the throttle body.

Joined
Dec 10, 2007
Messages
9,155
@Josh714 : Good deal; so they pressed a new plug into place?

Got photos of the old plug , or the replacement before they installed it, or
the TB after installation??

Last edited:
Joined
Dec 10, 2020
Messages
10
Location
Newport Beach, CA, USA
@Josh714 : Good deal; so they pressed a new plug into place?

Got photos of the old plug , or the replacement before they installed it, or
the TB after installation??
I thought I took these pics for my own records as well, but I didn't... The shop that made the repair showed me the piece they drilled out. It was some orange material... Yeah. I see now why no one welds these ports shut. haha, close call. The shop drilled out the leaking port and pressed two plugs with two layers of cold weld. The mechanic seemed confident. I'll give er a try and maybe I'll get a little vacation in Death Valley someday. ;)
