Bolt on 80 Series Tire Carrier Compatible with Factory Bumper

This site may earn a commission from merchant affiliate
links, including eBay, Amazon, Skimlinks, and others.

Running a sale until July 10th
Untitled (1).webp

VAcruiser said:
Hey!

I noticed your message on your site about having a baby; congrats! I'm not sure how old that message is so I don't intend to push. Are you still on hold for production?
Click to expand...
I have one for sale with all the accessories if you are still looking for it. It is a great carrier, and I wish I could stick with it!
K

SOLD Thread 'San Diego, CA: FJ80/FZJ80 - Tire Carrier/Swing - General Green Manufacturing'

Tire Carrier Swing for an 80 Series Toyota Land Cruiser or Lexus LX450

Looking to sell the complete carrier for $1000.

Shipping is approximately $450 to go back east, so shipped price will be $1250

Powdercoated Green (I paid about $300 for RAL 6009 Green)

Has been used for about 2000 miles, but the frame of the vehicle has pre-existing rust which is affecting my ability to use it safely. There are scraped and bolt tightening marks on the Strike plate that are cosmetic and do not affect function.

This unit easily holds my 37" Tire with very little movement over street use, and did...

GGM said:
For those that need a spare tire carrier but don't want to spend thousands on a new bumper, here's the solution. These pictures are of the first prototype, minor changes may be made.

View attachment 3131566View attachment 3131567View attachment 3131568View attachment 3131579

This kit is mostly bolt on, a hole will need to be drilled through the bumper plastic and some of the plastic on the middle of LX models (as shown). There are also 2 threaded holes on the frame of 93-97 models that were used. 91 and 92 model years will require a bracket to be cut off the frame and 2 holes to be drilled. NO WELDING NECESSARY.

Features:

CNC cut from ¼” USA steel, designed and assembled in Tampa Florida.

Kit includes all hardware needed for installation. Grade 8 or equivalent mounting hardware. Lug nuts not included.

Locking latch handle.

Greaseable roller bearing spindle

Will be shipped bare, unpainted; however, I am looking into powder coat and LineX bedliner options.

Fits up to a 37” tire without blocking the tail lights

The swinging portion is about 45 pounds and the entire assembly is about 65.

Happy to post more pictures or answer any questions. Any feedback is welcomed. I will keep this thread up to date on any changes or additions.

Price is $820 shipped domestically.

www.generalgreenmanufacturing.com

80 Series Bolt On Tire Carrier | GGM

The GGM family is growing! My wife and I are expecting our first child! With that, I am taking a break from building anything for a few weeks until we get back into routine. For now, please sign up for notifications using the Notify When Available button. That way, when I open orders back up you...
www.generalgreenmanufacturing.com www.generalgreenmanufacturing.com
Click to expand...
When are you making more i have a 92

Congratulations on having a baby! When you’re back, do you have an ETA on when they will be back in stock? Thanks!
