Nice work! Got any tips for welding exhaust? I'm thinking about doing mine too but I'm a new welder and have heard exhaust can be tricky.

Joined
Nov 20, 2010
Messages
567
Location
Socal
Nice work! Got any tips for welding exhaust? I'm thinking about doing mine too but I'm a new welder and have heard exhaust can be tricky.


Use .023 wire! I had to use .030 because I had about 20lbs of it and only 2lbs of .023 and that little roll doesn't fit in the big welder. I found it way easier to use the smaller wire. The other thing is weld as much as you can on the bench, you can see the welds I did lying on my back burning the crap out of myself...

Joined
Jul 9, 2020
Messages
19
Location
Templeton, CA
Thanks for taking the time to post the build thread. Did you end up using all 2-1/4"? I was looking at mine and wondering if I could use a bit larger tube and squash it oval to create more free space between the floor and the exhaust.

Joined
Nov 20, 2010
Messages
567
Location
Socal
Thanks for taking the time to post the build thread. Did you end up using all 2-1/4"? I was looking at mine and wondering if I could use a bit larger tube and squash it oval to create more free space between the floor and the exhaust.

I ended up using 2-1/4 the whole way, I could find zero evidence to suggest that larger diameter would pipe would actually make any difference in performance. For the part that goes over the frame, it is pretty tight as is, plus I wrapped it with two layers to try and keep the floor a bit cooler so with even 2.5 it would be touching.

P.S. I have an extra 6" round muffler if you want, I bought two to see the difference.

Joined
Jul 9, 2020
Messages
19
Location
Templeton, CA
Did you remove the rear heater completly?
I ended up using 2-1/4 the whole way, I could find zero evidence to suggest that larger diameter would pipe would actually make any difference in performance. For the part that goes over the frame, it is pretty tight as is, plus I wrapped it with two layers to try and keep the floor a bit cooler so with even 2.5 it would be touching.

P.S. I have an extra 6" round muffler if you want, I bought two to see the difference.
It looks like it's a tight squeeze
Yes I would happly find a home for your extra muffler if you think it will work

Joined
Nov 20, 2010
Messages
567
Location
Socal
I haven't done anything, but was thinking of capping the heater lines at the firewall...thoughts?

Joined
Nov 20, 2010
Messages
567
Location
Socal
I'll have to do a bit of looking, thinking and asking, but I would just as soon remove as much as possible as soon as I figure what that is. I'm sure there are probably 614 threads on it I can read...


davidp14

SILVER Star
Joined
Mar 24, 2017
Messages
740
Location
Staunton, VA
I deleted my rear heater. Easy peasy. Theres a few pics and tips in my build thread in my sig. I left my hard lines in place, too much work to remove. I keep two large tool bags under the seat now.

Joined
Nov 20, 2010
Messages
567
Location
Socal
Ok, all dialed in. There is one leal, but I know where and why (weld on the very top) and how to fix it. Happy to help anyone considering running over the frame ..tight but doable. All said, I'm into it for about 320 with consumables. I could probably do it for about 260-280 if I did it again.

Joined
Apr 17, 2018
Messages
620
Location
Pensacola, FL
Ok, all dialed in. There is one leal, but I know where and why (weld on the very top) and how to fix it. Happy to help anyone considering running over the frame ..tight but doable. All said, I'm into it for about 320 with consumables. I could probably do it for about 260-280 if I did it again.
That little? That's pretty awesome. I will definitely be considering this as an option in the next year or so. My exhaust is a patchwork arrangement of rusty OEM components, PO hack job, and my hack job repairs haha.
