I’m trying to be precise as I set up some knuckles on my 47. I have the knuckle alignment tool and followed these directions.
Knuckle alignment tool
When I take the measurements these are the measurements I get.
Obviously my total shims can’t equal 12.55 with 11.35 on the top.
Only thing I can think of is I’m using mini truck knuckles.
My thoughts were to place the bottom shims to the thickness indicated then adjust place about the same on the top then check preload and adjust as necessary.
What are your thoughts?
