Foglights - 80 Series factory foglights that should have been, maybe?

[96bruzer]

Foglights 80 Series factory foglights look

Just wanted to share this to my fellow mudders since I have had several people ask and compliment my factory looking foglights.

Foglights I used are for Ford F250's I got from ebay - depot lights and I still need to have bumper painted.

FZJ80 Series factory foglights on stock bumper, is this what it should have been, maybe?

Please show me your aftermarket foglights and set up on stock or aftermarket bumper.

By the way, I am after the look...



[andhop72]

Do you have a write up on these.



[sco68fj40]

Those look good on there. How well do they work though?



[98 SNAKE EATER]

Very nicely done



[SIZZLE]

Very clean install. What did you use to cut the holes?



[Duiser Offroad]

Looks good, those would be nice in an aftermarket bumper too.



[Otamiway]

Very sleek install. Can you post some pics of the backing??

Good Job
Stu



[aktundra]

Are they fog lights or spot lights?



[96bruzer]

Do you have a write up on these.

Yes, I will have it soon with pics.

Those look good on there. How well do they work though?

They work just like '05 Ford F250 factory fog lights.

Very nicely done

Thanks Snake Eater!

Very clean install. What did you use to cut the holes?

Air grinder and air drummel tool but you can use anything that will cut the bumper.

Looks good, those would be nice in an aftermarket bumper too.

I know, but it might be hard to cut into those because they are thicker. But it can be done. Hope to see it in a aftermarket bumper soon.

Very sleek install. Can you post some pics of the backing??
Yes, I will have the write up soon with pics.
Good Job
Stu

Thanks!

Are they fog lights or spot lights?

They are '05 Ford F250 factory fog light from Depot Lights



[96bruzer]

I did this about a year ago so let me know if I miss any details. Sorry for the bad cell phone pictures.

1st pic; I bought 2005-07 Ford F250 depot fog lights from ebay and it came with a small cutout cardboard inside the box that is shaped like the foglights. This is what I used to make the corners of the foglights on the cardboard which is in pic #2

Pic #3 inside measurements are 4 2/16" x 4 2/16. You can make it bigger or smaller. Its up to you

pic #4 cut out card board

pic #5 tape onto bumper where you would like it

pic #6 draw your lines and you can tape around it if you like

pic #7 cut out cardboard is 2 3/4 away from bumper grill insert

pic #8 cut with grinder first and then clean up with dremmel

pic #9 cut the top and bottom of the foglight brackets so they can fit the inside of the buper and install home depot brackets.

Don"t forget to make holes for bolts bigger than bolts so you can make adjustments of foglights. I bought the bolts that looks like the bumper bolts at home depot also. Install on bumper and then align your lights.

Thanks everyone!



[96bruzer]

More Pics.



[96bruzer]

More Pictures.



[96bruzer]

More Picture...



[thatcabledude]

VERY nice job. I would have to make them yellow though. I'm a sucker for yellow fogs.



[Itchy Sides]

Nice, clean job. Factory fog switch, or...?



[96bruzer]

VERY nice job. I would have to make them yellow though. I'm a sucker for yellow fogs.

I was debating on that too, thanks!



[96bruzer]

Nice, clean job. Factory fog switch, or...?

I got this kind.



[thatcabledude]

When your ready....



[Solid Taco]

Nice work. Subscribed. Have you searched if they have bulbs for those in yellow? I like fogs in yellow too. Thanks.

Cary



[96bruzer]

thatcabledude, nice spray paint with lots of potential/use.

Solid Taco, yes they are available for the Ford F250's 9145 fog light bulbs.

http://www.google.com/#hl=en&tbo=d&...5cb46a70252cd5&bpcl=40096503&biw=1366&bih=651
