70 windshield info ??

[In2cruisers]

In search for a windshield for my LJ-70.. Hard top..(aftermarket... Dont want to throw down $600 ) during some of my search...found a company who may stock for a FJ-70
Since I have only been around a couple 70s...one being mine. I just want to make sure they are all the same



[cruiserdan]

I just ordered a factory windshield for my BJ74 today.

PM me the VIN on your LJ70 and I will see if I can determine the part number.



[winoism]

Hi just going thru your tread. Is your LJ equipped with a fold down from window of fixed frame. I need a windshield for my HJ75. Let me know who you ordered it from and a part number.( if it's different from toyotas). Much appreciated Mark



[In2cruisers]

Hi just going thru your tread. Is your LJ equipped with a fold down from window of fixed frame. I need a windshield for my HJ75. Let me know who you ordered it from and a part number.( if it's different from toyotas). Much appreciated Mark

She's a fixed top... Cdan informed me today, that that OEM are still available here. But for now I'm still on the hunt for aftermarket. >$$s



[kbushnz]

According to toyodiy... The 1990 LJ70 of North American descent is
56111-90K04

And is also fitted to the following....

01/1990-07/1992 fj70rv-mrq std, arl, ht, rhd, 3f, cbr, mtm, 5f, cbu 55-53
01/1990-07/1992 fj75rv-mrq std, arl, ht, rhd, 3f, cbr, mtm, 5f, cbu 55-53
05/1993-12/1994 hzj70rv-mrq std, arl, ht, rhd, 1hz, dsl, mtm, 5f, cbu 55-53
01/1990-04/1993 hzj75rv-mrq std, arl, ht, rhd, 1hz, dsl, mtm, 5f, cbu 55-53
01/1990-07/1992 lj70rv-mnxq lx, arl, ht, rhd, 2lt, td, mtm, 5f, cbu 55-53
01/1990-07/1991 pzj70rv-mrq std, arl, ht, rhd, 1pz, dsl, mtm, 5f, cbu 55-53
01/1990-07/1991 rj70rv-mnq lx, arl, ht, rhd, 22r, cbr, mtm, 5f, cbu 55-53

Also got a hit on this
http://quickparter.com/oem-parts/5611190K04.html
Has alt P/N to.... 56111-60220



[John Galt]

I just ordered a factory windshield for my BJ74 today.

What is the the part number



[In2cruisers]

what is the the part number

56111-60220 per Cdan



[cruiserdan]

What is the the part number

56111-60230 for mine. That one is "tinted".



[winoism]

Cruiserdan. Did you order it online through a Toyota dealer? Can I ask how much with shipping? You can pm me if you wish. I'm worried about breakage in transport. Thanks Mark



[cruiserdan]

Well, I ordered it from myself actually.

The published list price is $653.30. I sell them for $489.97 local pick up. I do not ship out large pieces of glass. The freight is killer and the breakage is high.
In addition it is very difficult to get damage claims paid on glass.



[winoism]

Where would I pick one up from you?



[cruiserdan]

Albuquerque.



[winoism]

You know what that means..... ROAD TRIP. I'll be in contact when I need one shortly to confirm you still have one available. Thanks



[In2cruisers]

You know what that means..... ROAD TRIP. I'll be in contact when I need one shortly to confirm you still have one available. Thanks

And Taos is opening on the 28th with 48" and comming down 12" in the last 24hrs

LOVE this place


.



[toyobaru]

Awesome. I want to ski pow AND buy a new windshield! Maybe this spring...



[ForealBoreal]

Awesome. I want to ski pow AND buy a new windshield! Maybe this spring...

I just want POW! Ordered some BD Gigawatts the other day



[John Galt]

56111-60220 per Cdan

56111-60230 for mine. That one is "tinted".

is the 60220 the clear version of the 60230 tinted?

both fit the late model BJ-74 with fold-down windshield?



[cruiserdan]

is the 60220 the clear version of the 60230 tinted?

both fit the late model BJ-74 with fold-down windshield?

The cataloging I have been able to research is inconclusive. Depending on where you look you will find over a half dozen 7x windshield part numbers.

I am certain that the 60230 is the "correct" (superceeded) glass for my 1988 BJ74 FRP (folding frame). I have also found a reference to the very same glass applying to a 78 Series troopie (fixed frame).

My gut feeling is that all 7x Series vehicles have the same windshield opening and there are two current part numbers. 56111-60220 clear and 56111-60230 tinted.

That is a wild-ass guess, based on a lot of looking and 35 years of dealing with Toyota parts.

That and 9 bucks will get you a high-class micro-brew 6-pack.....



[rick_d]

56111-60220 is fixed top, 56111-60230 is fold down.

plain gasket fixed is 56121-60120, fold down 56121-90K01

this should just be a sticky by itself.

fold downs are shorter in height than fixed



[cruiserdan]

56111-60220 is fixed top, 56111-60230 is fold down.

plain gasket fixed is 56121-60120, fold down 56121-90K01

this should just be a sticky by itself.

fold downs are shorter in height than fixed

Perfect. Thank you.
