Looks nice Matthew. I am looking forward the ring getting machined. How much do you plan on taking off of it?
possible 14 bolt for my 40 (1 Viewer)
- Thread starter 69LC
- Start date
This site may earn a commission from merchant affiliate
links, including eBay, Amazon, Skimlinks, and others.
- Joined
- Jan 12, 2008
- Threads
- 290
- Messages
- 3,485
- Location
- West MI near GVSU
- Website
- www.mcdesignsoffroad.com
- Thread starter
- #22
Slight Progress...
I haven't gotten far enough to get the carrier and ring gear back in. I'm currently trying to get the spindles back onto the tubes before I lose my big welder access. I was able to machine one of the tube sleeves completely the other day, and part of the other. Tonight I drilled the right side tube and spindle half and slide-hammered them together using a wasted Ford 9" axle shaft. The attached pics show a gap that will go away prior to welding.
I haven't gotten far enough to get the carrier and ring gear back in. I'm currently trying to get the spindles back onto the tubes before I lose my big welder access. I was able to machine one of the tube sleeves completely the other day, and part of the other. Tonight I drilled the right side tube and spindle half and slide-hammered them together using a wasted Ford 9" axle shaft. The attached pics show a gap that will go away prior to welding.
- Joined
- Jan 12, 2008
- Threads
- 290
- Messages
- 3,485
- Location
- West MI near GVSU
- Website
- www.mcdesignsoffroad.com
- Thread starter
- #23
one year later, a bit more progress...
This has to be one of the slowest axle builds. The last pics I posted were about now last year.
My cousin milled down the cover surface for me. He will still add a couple of more tapped cover holes in the fill plate.
This has to be one of the slowest axle builds. The last pics I posted were about now last year.
My cousin milled down the cover surface for me. He will still add a couple of more tapped cover holes in the fill plate.
- Joined
- Jan 12, 2008
- Threads
- 290
- Messages
- 3,485
- Location
- West MI near GVSU
- Website
- www.mcdesignsoffroad.com
- Thread starter
- #24
recent progress
My cousin machined my shaved 14B housing. It still needs a final pass and redrilling for cover holes. In the mean time I have nearly finished my yoke-flange conversion. I have the pilot holes drilled for mini truck and fj60 driveshaft flanges.
The 9" has a lincoln versailles flange modded for Toyota shafts too.
My cousin machined my shaved 14B housing. It still needs a final pass and redrilling for cover holes. In the mean time I have nearly finished my yoke-flange conversion. I have the pilot holes drilled for mini truck and fj60 driveshaft flanges.
The 9" has a lincoln versailles flange modded for Toyota shafts too.
Are you using an axle jig to make sure you get those spindles welded on straight? I just got a quote for $495 for a 14bolt jig.
- Joined
- Jan 12, 2008
- Threads
- 290
- Messages
- 3,485
- Location
- West MI near GVSU
- Website
- www.mcdesignsoffroad.com
- Thread starter
- #26
I haven't figured out what I will do yet. The tube splices are a tight fit, but I will probably make an alignment bar and use weld passes to straighten the tubes if needed.
That yoke-flange is Awesome!
http://www.youtube.com/watch?v=EmJwNdXy9f4&noredirect=1
Dean from Kick Ass Off Road quoted be USD$450 +Shipping for this very bar that Ruff Stuff is using in this video. A guy with a lathe and an evening on his hands could make the pucks. But I don't have a lathe...
