ISO: No Head Unit Ham Radio

Joined
Feb 4, 2018
Messages
150
Location
Apple Valley, CA
I used to have a CB that had the radio itself in a body that could be mounted anywhere, then the controls were in the mic. I’m looking for a similar setup for HAM and thus far have struck out. I don’t have a good place to mount a faceplate and I use it so infrequently I’d prefer the ability to put it away completely out of sight. Anyone know of such a unit?


WB8LBZ

GOLD Star
SILVER Star
Joined
Dec 29, 2013
Messages
233
Location
El Paso, TX
I am currently using an Icom IC-2730 that has a detached control and a Mic with keypad. Its a VHF/UHF radio, I'm not sure if that is what you are interested in. I can have the control anywhere I can see it and the Mic can plug into the radio or the control.

Larry in El Paso, TX


WB8LBZ

GOLD Star
SILVER Star
Joined
Dec 29, 2013
Messages
233
Location
El Paso, TX
The closest thing to that I saw was a Motorola system installed in a government vehicle and that was a few years ago.

Larry in El Paso, TX


Elbert

SILVER Star

Joined
Jul 20, 2006
Messages
8,850
Location
AL, USA
I don't think there is one in the ham world like you are asking about, where all the controls are in the mic, there are some with a remote faceplate and the body of the radio mounts wherever

Joined
Dec 28, 2015
Messages
80
Location
Appleton Wisconsin
The main issue with Ham is that it is not channel based. Most units do allow you to have memory channels that are associated with frequency's or repeaters. Most allow you to page up and down on the mic but do not have a display on what memory you are on.

Joined
Sep 20, 2011
Messages
564
Location
Caracas, Venezuela.
The only radios I can think of that have controls on the mic, other than CB units, are GMRS units.

The closest you can get, is a remote faceplate unit. You mount the main body of the unit hidden and out of the way, and only need to figure out where to mount the faceplate and mic.

I'm running an Icom 2730 as well, one of the only analog VHF/UHF detachable units in the market. It was also the only one that came detached from factory. Contrary to every other manufacturer, Icom offers the 2730 detached and you need to purchase an additional kit if you wish to attach it to the main body.

Kenwood, Yaesu both have a few good options as well, you just have to figure out what features you need. I decided on the 2730 mainly because I need no alternate bands or digital capabilites. Yaesu's detachable-faceplate units are either quad band units or digital units, no analog. The Kenwood V71 is similar to the 2730 but it is more expensive and I don't need echolink capabilities, also I believe you need to purchase a kit in order to detach the faceplate.


WB8LBZ

GOLD Star
SILVER Star
Joined
Dec 29, 2013
Messages
233
Location
El Paso, TX
I saw a listing for a 40 for sale that had a CB with Cobra Mic that had a small display. Maybe this is what you were thinking about.

Larry in El Paso, TX

Joined
Dec 28, 2015
Messages
80
Location
Appleton Wisconsin
Another choice would be a small HT like the FT-4XR. The whole radio is about the size of the Cobra Mic. If you want more than 5W out you could add a LA-44 amplifier that will get you 70W out.
