I have been asked what is included in "full option" so here is the full specs and options of my GX:
Full Specs
EXTERIOR DIMENSIONS
Wheelbase 109.8 in.
Overall Length 188.2 in.
Overall Width 74.0 in.
Overall Height (unloaded) 73.0 in.
- With optional roof rack 74.6
Tread Width - Front 62.2 in.
- Rear 62.2 in.
Minimum Ground Clearance 8.3 in.
Approach Angle - “Normal” setting 31 deg.
- “High” setting 30 deg.
Departure Angle- “Normal” 25 deg.
- “High” 29 deg.
INTERIOR DIMENSIONS
Seating Capacity 8 (Has optional third row seat)
Headroom - Front 40.2 in.
- Middle 40.0 in.
- Rear (optional) 36.5 in.
Legroom - Front 41.8 in.
- Middle 36.8 in.
- Rear (optional) 24.9 in.
Shoulder Room - Front 57.5 in.
- Middle 57.4 in.
- Rear (optional) 56.7 in.
Hip Room - Front 55.1 in.
- Middle 54.8 in.
- Rear (optional) 56.4 in.
Total Interior Volume 153.6 cu. ft. (147 with 3rd row seat)
Cargo Volume - Rr. seat down, 3rd row seat removed 77.5 cu. ft.
- Rr. seat up, 3rd row seat removed 49.7 cu. ft.
- Rr. seat up, 3rd row seat to side 39.8 cu. ft.
- Space behind 3rd row seat 13.2 cu. ft.
WEIGHTS AND CAPACITIES
{b]Curb Weight 4,871 lbs.
GVWR 6,200 lbs.[/b]
Weight Distribution – Front / Rear 53% / 47%
Maximum Towing Capacity 6,500 lbs. (with appropriate hitch)
Fuel Capacity 23 gal.
ENGINE
Type, Materials V8, cast iron block and aluminum heads
Designation 2UZ-FE
Valvetrain DOHC 32 valve with continuously variable valve
timing with intelligence (VVT-i)
Displacement 4.7 liter
Bore x Stroke 3.70 in. x 3.31 in.
Compression Ratio 10.0:1
Horsepower (SAE) 270 @ 5,400 rpm
Torque 330 lb.-ft. @ 3,400 rpm
Maximum Engine Speed (redline) 5,700 RPM
Fuel System Sequential Multi-port Injection (SFI); Electronic Throttle
Control System with intelligence (ETCS-I)
Emission Certification ULEV-II
DRIVETRAIN
Layout Front engine, full-time four wheel drive (4WD)
Transmission Type 5-speed automatic, electronically controlled (ECT);
gated shifter; second gear start feature
Designation A750F
Gear Ratios 1st 3.520
2nd 2.042
3rd 1.400
4th 1.000
5th 0.716
Reverse 3.224
Differential Gear Ratio 3.727
Transfer gear ratio H4 / L4 1.000 / 2.566
Center Differential Type TORSEN limited slip with manual locking feature
CHASSIS AND BODY
Body / Frame Steel body mounted on steel perimeter frame
Suspension - Front Double wishbone, coil springs, stabilizer bar
- Rear 4-link rigid axle, control arms, air springs, stab. bar
- Damping and height controls 4-wheel Adaptive Variable Suspension (AVS);
Adjustable Height Control (AHC) rear susp. only
Steering - Type Engine speed sensing power assisted rack & pinion
- Overall Ratio 15.7:1
- Turns, Lock to Lock 3.04
- Turning Circle (curb to curb) 37.4 ft.
Brakes - Type Four wheel disc with Anti-lock Braking System (ABS),
Brake Assist and Electronic Brake force Distribution (EBD)
- Front 13.3 in. vented disc
- Rear 12.3 in. vented disc
Anti-lock Braking System 4 channel, 4 sensor
Wheel Size / Type 17x7.5 JJ / alum. alloy
PERFORMANCE
0 – 60 MPH Acceleration (mfr. results) 8.1 sec.
0 – 1/4 mile Acceleration (mfr. results) 16.3 sec.
Top Track Speed (mfr. results) 112.5 mph (electronically limited)
EPA Estimated Fuel Consumption – City / Highway 15 / 19 mpg
Coefficient of Drag (Cd) 0.38
EXTERIOR FEATURES
Overall Exterior Styling/Body Design
• Headlamps (projector type), running board lamps, and reverse lamps with green tint
• Prominent front grille that features three horizontal bars
• Distinctive character lines on the hood
• Color-keyed fender flares, running boards, bumpers, door handles, mirrors, lower body cladding, and roof rack
• Front bumper with integrated fog lamps
• Three stack design sculpted rear tail lamps with reverse lamps located under license plate garnish
• Rear tailgate swings out like conventional side door instead of lift-gate style (hinged on the right)
• Front glass with UV protection and green tint
• Privacy glass on rear windows
• Rear mudguards (front mudguards integrated into running board design)
Body Structure and Paint
• Reinforcements throughout body structure for improved rigidity
• Silencing material installed throughout vehicle
• 3-coat paint with scratch resistant anti-acid rain clear coat
Features/Options
• Power tilt/slide moonroof with one touch open/close feature, jam protection, and speed-sensing wind deflector
• Aerodynamic heated outside mirrors with manual folding and reverse auto-tilt
• Auto-dimming electrochromic inside rear view mirror
• Integrated illuminated running boards with Lexus “L” emblem on the scuff plate
• Fuel cap tether
• Auto on/off headlamps with variable off timing
• Water repellent front door glass
• Rain sensing, variable intermittent front windshield wipers
• Intermittent rear windshield wiper with washer
• Hood struts
• Roof rack (color-keyed rails with black cross bars) with 130 lb. capacity
• Towing package (includes pre-wire for trailer lights)
INTERIOR FEATURES
Interior Trim
• gray leather trim seat facings, headrests, armrests, door-trim, shift ****, and steering wheel with chrome “L” emblem
• Genuine Golden Bird’s Eye Maple wood trim on dashboard, center console, door panels, steering wheel and shift ****
• Front and rear door pockets; front seat back storage pockets
• 10 interior assist grips
• Dual sun visors with slide mechanism and illuminated vanity mirrors
• Chrome door handles
• Cut pile carpeting; carpeted floor mats and cargo mat
Seats and Cargo Area
• Foldable and reclining 60/40 split second row seat with CRS anchorage
• Front seat mounted armrests and rear seat center armrest with pull-out cupholders
• 10-way power driver's seat (power adjustments: fore-and-aft slide; fore-aft recline; front vertical height, rear vertical height, and lumbar support) with 2-position memory
• 6-way power front passenger’s seat (includes power lumbar support for ’05)
• Heated front seats with variable heat setting
• Chrome tie-downs located on the floor of the cargo area
Instrumentation and Controls
• Lexus Optitron instrumentation
• Electronic odometer/twin trip meters
• Compass (in electrochromic inside mirror)
• Soft-touch fully automatic climate control with smog sensing auto-recirculation system, anti-dust filter, and separate driver & passenger temperature controls
• Front defroster-linked A/C startup control; rear swing door and quarter window defoggers with auto-off function
• Digital outside temperature display, digital clock, and trip computer (avg. mpg, current mpg, range, avg. mph, barometer, altimeter, elapsed time)
• Scheduled maintenance indicator light
• Remote operation of windows and optional moonroof
Convenience Features
• Auto-dimming electrochromic inside and outside mirrors
• Electronic programmable garage door opener located in overhead console map light assembly with sunglass holder
• Front interior “lounge” illumination
• Door courtesy lights, glove box light, dome light, front map lights, and rear cargo area light
• Illuminated cigarette lighter and 12 volt power outlet in center instrument cluster
• 115V outlet (located on passenger side of rear cargo area)
• Power door locks with anti lock-out feature and driver's door two-turn unlock system
• Manual (swing-out type) rear quarter windows with privacy glass
• Power tilt-and-telescopic steering wheel column with automatic tilt away
• Steering wheel-mounted cruise control switches, audio controls and voice command button for navigation
• Rear Seat Audio system (RSA) Includes remote control and holder (holder attaches to seat back pocket)
• Headrests for all seating positions
• Manual seat belt anchor height adjusters for front seats and 2nd row outer positions
• Remote fuel filler door release; fuel cap hanger
• Storage pocket with cargo net integrated in the rear door
• First aid kit; Tool kit
Optional Features
• Upgraded Lexus DVD Navigation System with 5.6 million points of interest, new graphic interface and building footprint display in major cities; includes Bluetooth capability and
steering wheel mounted voice control button
• Rear back-up camera
• DVD Rear Seat Entertainment system (RSE) - DVD player located in center console and screen folds down from the ceiling – includes two wireless headphones and Rear Seat Audio (RSA) functionality
• Foldable and removable (via quick release mechanism) 3rd row seat with 50/50 split – provides 8- passenger seating (2-3-3) and includes rear A/C
AUDIO SYSTEMS
Mark Levinson Audio
• AM/FM auto-reverse cassette
• Six-disc CD auto-changer (glove box-mounted changer)
• Dolby B and C noise reduction for cassette
• 14 speakers incl. sub-woofer, center spkr.
• FM diversity sub-antenna (right rear quarter glass)
• Automatic Sound Levelizer (ASL)
• 124W @ 0.1 THD • Eight channels, 240W @ 0.01% THD
• Ultra-low crossover distortion
• State-of-the-art discrete amplifier design
SAFETY AND SECURITY
Safety
• Supplemental Restraint System (SRS)
- Advanced driver and front passenger airbags with seamless passenger-side airbag cover
- Front seat-mounted side airbags
- Roll-sensing front and rear side-curtain airbags (1st and 2nd row only)
• Seatbelts
- Driver and front passenger’s pretensioners and force limiters
- ALR/ELR for all positions except driver
- 3-point seatbelts for all seating position
• Daytime Running Lamps (DRL)
• Impact-dissipating upper interior
• Side impact beams
• Four-sensor Tire Pressure Monitor system (TPM)
• High-stability dynamics
• High roof crash strength
• Active TRAC (A-TRAC)
• Vehicle Stability Control (VSC)
• Downhill Assist Control (DAC)
• Hill-start Assist Control (HAC)
• TORSEN LSD (center diff.)
Security
• Key integrated rolling code remote entry
• Key card immobilizer
• Vehicle security system
• Shift linked auto door locks
• Key cylinder in driver’s door only
