Sliding rear window leak

This site may earn a commission from merchant affiliate
links, including eBay, Amazon, Skimlinks, and others.

Joined
Oct 10, 2010
Threads
131
Messages
1,231
It looks like it may be coming from where the trim piece clips connect to the body. It appears to be originating there then rolling down. I had a similar issue and I put a glob of RTV on the underside of each of the clips and that seems to have helped.

It looks like it may be coming from where the trim piece clips connect to the body. It appears to be originating there then rolling down. I had a similar issue and I put a glob of RTV on the underside of each of the clips and that seems to have helped.

X2 remove the trim and use RTV in the clip holes to stop the flow of water from coming in.


Have you ruled out the rear sunroof drain tube on that side? If it has come off it may be the source. Try running a hose on low on top of your sunroof being careful not to get any water on the side by letting it drain via the rain gutters. Look inside and see if you can see where the water starts coming in to start with. If it stays dry then it's the side you run the water on next just at the trim area trying not to get the window wet and so on to find your source.

Last edited:
Just to update this , I did cleaned the holes under the rubber runs( don't know the name) and then applied an rtv on the sides of the weather stripping .... No more leaks. Pretty much the rubber type weather stripping aren't tight anymore applying a sealant seals it. Hope it helps . Thanks

I had same leak from the clip that holds the window molding. The big tube (sunroof drain?) somehow got pulled out of its exit hole in the fender.
The weep holes must of got plugged and now there is a hole you could put a baseball through. Put a little RV sealant on the clip, cut some old license plates to use a patches and use what RV sealant I had on hand and all is good for now. I need to get a bottle of expanding foam to fill the bottom section of the fender. I will slope the foam and install a straw to drain off any more water that enters.

Check and clean your weep holes and you wont have rust like I do.
