HJ45 rear Bumper Build

[24HOURSOFNEVADA]

Well it seems like all the cool kids are doing it, so I thought I would follow along.

I've been gathering parts for awhile and thought I should hit it hard before I start my 80 series engine rebuild.

I posted in the 45 section, but thought I would post up here as well.



[24HOURSOFNEVADA]

I live so close to Chicago, that he could probably hear the cold saw screaming.



[24HOURSOFNEVADA]

I made a mounting plate that bolts to a custom heavy crossmember. The receiver bolts to the frame. There will be outriggers to support it as well.



[24HOURSOFNEVADA]

The gusset's for the safety chain. I need to shave off about another 1/8" so the bumper sits flush with the receiver.



[24HOURSOFNEVADA]

I left the width long, because I have a matching camper shell and I'd like to leave that space for sleeping and living. Therefore swingouts are needed for the spare tire and wedco diesel cans.


I'm just not crazy about the shape of the 45* cuts and the extra width.



[24HOURSOFNEVADA]

The passenger side...



[24HOURSOFNEVADA]

Here's a pic of the shell.



[24HOURSOFNEVADA]



[chicago]

Looking GOOD!
I wear ear plugs, so I can hardly hear anytihng!

Nice job!

K



[chicago]

BTW, where did you pick up those SCHNAZZY gussets from?
Diggin em!

K



[24HOURSOFNEVADA]

BTW, where did you pick up those SCHNAZZY gussets from?
Diggin em!

K

Thanks man. I was wearing ear plugs as well. I'm already deaf. Don't need to be anymore.


They came from Blue Torch Fab.



[chicago]

Thanks man. I was wearing ear plugs as well. I'm already deaf. Don't need to be anymore.


They came from Blue Torch Fab.

AYE!
They sure look cool...the gussets that is!
Sure is a sweet rig! Its a RHD as well, correct?

M hearing is diminshing as well, so I make a point of slowing down a bit to put them in!

K
