You mean something like this? I have been modelling this for my '69 to have the flat patterns laser cut out. It is not perfect yet but getting close. Once complete I may post some dxf files for people to use. There are many hours into this and it would be nice to get something out of it in the end...





Cheers,

Chris

Buskanaka said:
You mean something like this? I have been modelling this for my '69 to have the flat patterns laser cut out. It is not perfect yet but getting close. Once complete I may post some dxf files for people to use. There are many hours into this and it would be nice to get something out of it in the end...

View attachment 4020586

View attachment 4020589

Cheers,

Chris
Click to expand...
Awesome thanks a lot mate .

started checking my CAD to 3D scans of some old bent up and rusted original parts. My CAD is pretty darn close for a first run at it. A little tweaking and it should be very good and be ready for laser cutting!





When I am done, I might be willing to give some of it out to an individual to help them on their personal build but I do not want someone to use it to start manufacturing knock-offs in Asia etc. I hope people understand why I am not going to just post up this data. I did post up CAD for the rear frame member and cross braces as they not all that complicated and you can just buy those parts per-made elsewhere.

Cheers,

Chris
