What have you done to your Land Cruiser this week? (9 Viewers)

brooklyn

SILVER Star
Joined
May 11, 2007
Messages
771
Installed City Racer carb and a new fuel filter. Runs better than ever!


Blue77FJ40

SILVER Star
Joined
Nov 30, 2004
Messages
2,659
Location
MD

Clubtroy

SILVER Star
Joined
Apr 9, 2020
Messages
129
Location
Houston, TX
Pretty amazing how well the bread trick works to get the input shaft bearing out of the back of the crankshaft. One bolt, electrical tape, a hotdog bun and hammer. Thanks to the experts for posting this in the 40 Forum! Now just have to get the new one in. I hear freezing the bearing and heating the race area help with insertion. It's going to be 100 in Houston this weekend so I have plenty of heating.


Ackcruisers

SILVER Star
Joined
Nov 24, 2019
Messages
1,012
Location
MA
Chasing down small things. Wiper linkage investigation revealed an important metal component missing on my truck. My windshield frame assembly was missing this part so fabricated one and attached it with the OG JB Weld. (I do not like using this stuff but if there was ever an application for it this was it).

Then installed jack handle extension brackets.







Pighead

Stop calling it an FJ
Joined
Aug 31, 2004
Messages
9,152
Location
Camino
I had envied those new 2F alternator tensioners I've seen lately. Was hesitant to buy one as i do not have a Toyota alternator. It's a Herr. When i swapped in the 2F block, i did not have the upper bracket or tensioner. So i made my old late F alt bracket fit.
Just pounded it between two rocks until it sorta fit. Then used a crowbar to adjust the tension.
Then i heard, after i asked, that i could get a good used one locally. So i did. (Thanks @pardion)
Simplicity itself to install, had to fiddle with bolts & washers & stuff. Probably should grind down the mount a little to make it perfect.






Joined
Jan 15, 2020
Messages
110
Location
KS
I had envied those new 2F alternator tensioners I've seen lately. Was hesitant to buy one as i do not have a Toyota alternator. It's a Herr. When i swapped in the 2F block, i did not have the upper bracket or tensioner. So i made my old late F alt bracket fit.
Just pounded it between two rocks until it sorta fit. Then used a crowbar to adjust the tension.
Then i heard, after i asked, that i could get a good used one locally. So i did. (Thanks @pardion)
Simplicity itself to install, had to fiddle with bolts & washers & stuff. Probably should grind down the mount a little to make it perfect.

View attachment 3028087

View attachment 3028088

View attachment 3028089
Not good to run the belt at that angle... will wear out prematurely

Joined
Apr 2, 2008
Messages
11,242
Location
Victoria, BC
I had envied those new 2F alternator tensioners I've seen lately. Was hesitant to buy one as i do not have a Toyota alternator. It's a Herr. When i swapped in the 2F block, i did not have the upper bracket or tensioner. So i made my old late F alt bracket fit.
Just pounded it between two rocks until it sorta fit. Then used a crowbar to adjust the tension.
Then i heard, after i asked, that i could get a good used one locally. So i did. (Thanks @pardion)
Simplicity itself to install, had to fiddle with bolts & washers & stuff. Probably should grind down the mount a little to make it perfect.

View attachment 3028087

View attachment 3028088

View attachment 3028089

I’m puzzled how belt alignment like that helps keep the power steering from throwing belts. Why can’t they all be aligned at the same time.


Pighead

Stop calling it an FJ
Joined
Aug 31, 2004
Messages
9,152
Location
Camino
I’m puzzled how belt alignment like that helps keep the power steering from throwing belts. Why can’t they all be aligned at the same time.
Perhaps Toyota-san did not envision Saginaw pumps on his early 2F block, i dunno.
I tried various iterations, with spacer, without, different belts & different pulleys, shimming funny.
I am not a guru. We all know that.
One run i tossed and or shredded 3 power steering belts.
This is the best i can do without professional help or starting a thread about it

Joined
Mar 2, 2015
Messages
2,484
Location
East of Eden, in the land of Nod
Perhaps Toyota-san did not envision Saginaw pumps on his early 2F block, i dunno.
I tried various iterations, with spacer, without, different belts & different pulleys, shimming funny.
I am not a guru. We all know that.
One run i tossed and or shredded 3 power steering belts.
This is the best i can do without professional help or starting a thread about it

Start a thread. There has to be a way around that problem.


Jdc1

SILVER Star
Joined
Sep 9, 2013
Messages
4,316
Location
Akron, OH
No, certainly not ideal. A compromise i made to keep the power steering from throwing belts
Grab some spacers to space the Alt back and then make a bracket to anchor at the head where the ground is. You’ll need to have the ear extended for the tensioner.

Joined
Apr 2, 2008
Messages
11,242
Location
Victoria, BC
I’m no expert either… I’d consider running a press on double pulley on the Saginaw pump. Or perhaps just a single press on pulley. The benefit of the press on ones is that they can be pressed on deeper or pulled back to align better. I bought a rebuilt core of a Saginaw pump for $46 CDN in store, so they are cheap enough. Mine was for a 3/4 ton Chevy pickup and has excellent pressure. Palm steering while stationary on dry pavement with 33x10.50s.

Joined
Aug 29, 2011
Messages
7,468
Location
Montana
