Broken Knuckle Stud

Joined
May 19, 2004
Messages
1,894
Location
Los Angeles

I broke one of the four knuckle bolts as I was finishing up my birth job. I replaced the bolt with one of the new style bolts, shown here.

I installed this new bolt with the short side in, once its properly torqued to the right spec, it still sticks out more than the other bolts. My question is, should it stick out more than the other bolts?


semlin

curmudgeon
Joined
Mar 27, 2003
Messages
5,346
Location
north of 49



i'd say that stud is way too blurry. I would return it and get one that is in focus. looking at that stud will eventually give you a headache unless you get bifocals.

Joined
May 19, 2004
Messages
1,894
Location
Los Angeles

I know, thats the best pic I could take. Need a macro lens to take better pics. but you can tell how much the bolt sticks out.


Brentbba

Former Golfer
SILVER Star
Joined
Mar 27, 2003
Messages
10,371
Location
OC, CA



jeez - and I just thought my reading glasses had suddenly gone bad! hehehe


semlin

curmudgeon
Joined
Mar 27, 2003
Messages
5,346
Location
north of 49



victor, Dan already answered your question. You could also compare the new stud to the old stud visually. Presumably it is longer or has shorter threads where it seats. I canb't tell which from the photo.
