germaneighter

My apologies. Didn't mean to offend you. As I mentioned in my private message to you last week I couldn't figure out how to attach pics in a private message. I'm just trying to figure this out.

Rainman, I recently received your FAL & RAL lines for my '77 40. The RAL is similar to the original but does not match. (three pics below) Do you bend the hump over the 3rd member differently than the factory bend? The new line looks like it...

Try this site. It has helped me many times. http://www.globalsoftware-inc.com/coolerman/fj40/DizzyFaq.htm

Thanks to all. pb4ugo- I'll need to do same, thanks

Below is a pic of a 1975 FJ40 that originally had stk 4 wheel drum. I added the 2 line bracket and made the nicop line going to the upgraded frt disc brake axle. I wanted the frt line to be similar to stk for disc. The rear line is original...

Skreddy, Never mind. I'm seeing your pics on "Skreddy bought a red one". Thanks you.

Skreddy, I'm getting there.... Would you have any pice of these lines across the back of the fire wall (up higher) and closer to the booster? thanks

Not sure if you still need it. Here’s my 77 with engine not installed.

Skreddy, thanks-very helpful. Thanks

thanks forks! this helps alot.

This might be what you are looking for

from a '78 but it should be the same. Had these on my phone. If you need a different angle I can get it later.

Thanks fyton2v. The '77 is slightly different due to the clutch line connection being farther to the right side than the '78. If you could get a shot of the two coiled lines going into the junction block that would be much appreciated. dg

My '77 had a severely bent frame and I was able to find a nice '74 frame as a replacement. Now that I'm to the point of installing all the brake lines I'm having a little trouble with hard line routing on the right side of the firewall and the...

I found a 3/8" X 1.625" fender washer that has the right diameter to retain the birf but doesn't interfere with the locking hub splines but the bolt hole was too large to keep it centered. I turned a small shoulder on a 8mm capscrew that keeps...

Thanks. I'm also concerned about it being too large and interfering with the lock out hub operation.

Just wrapping-up the front axle refresh. When I purchased the vehicle it had a descent pair of SuperWinch locking hubs that I'm reusing. The left side had a washer & nut at the end of the birf. The right side had nothing. You can see by the...
