need A/C! It's too hot here!

I have been surrendering to staying indoors because my '87 has no A/C or fan of any sort. recently it was working perfectly, but now, when flipping the switch, all i hear is the relay clicking, and no fan blowing. temperature controls all work, but the fan doesn't. help!


__________________
2001 Cadillac Deville DHS=cool car that needed over $10k in work done....
1986 Toyota truck.......completely clean, little rust.
1987 Toyota 4Runner.....for sale. Send PM.
lemming is offline   Reply With Quote



Old 07-01-09, 03:36 PM   #2 (permalink)
Forum Lifer


Texx's Avatar

Join Date: Feb 2002
Posts: 2,616
The fan probably needs replacing, it's located on the passenger side far right inside the cab. Look up under there, the round black part you see about 2" in diameter with two wires leading to it is the fan motor. Pull it (four screws) and check to see if it works by jumping to the battery. it doesn't=need to order fan. It does=check back thru the wiring to the fuse and switch.

__________________
world's cleanest 89 FJ-62, and a few parts... 85 xcab hilux 4x4 resto'ed, 67 XKE, 1500 Vulcan, 80 Fj40 restored SOLD:( 03 Tacoma TRD SR5, Suzuki DR350 Sold :(
Texx is offline   Reply With Quote
Old 07-02-09, 04:59 AM   #3 (permalink)
250+ Club


"N8"'s Avatar

Join Date: Oct 2006
Location: Boston Ma
Posts: 638
before it died did it only work on one or two settings for fan speed? I ask because there are a set of 4 resistors attached to the fan unit that always blow out. And when the resistor for whatever setting blows you loose that setting entirely till you replace the resistor.

__________________
-Nate
88 PU long bed, pro comp 35s
All Pro rear suspension
Custom SAS
Toyota e-locker(R),aussie(F)
4/88's
And a whole lot of dents contributed by new england's natural flora and fauna (mostly responsible is one species of flora... pine) (and the elusive new england delivery truck)
"N8" is offline   Reply With Quote
Old 07-03-09, 07:52 PM   #4 (permalink)
250+ Club


Join Date: Oct 2004
Posts: 393
Usually it's the resistor; located on the passenger's firewall in front of the glovebox, above the fan. Maybe it's the fan...easy (but cramped) to remove and check. If all else fails, see photo...
Attached Images


__________________
Pluton
'91 4x4 regcab, 22re,4.56's w/ 31's, BudBuilt CM, Bilsteins, no REAL mods...no more 87 FJ60, or '85 FJ60.
Santa Monica,CA
